Page 29
English
_
English
You can specify MASK 1 and 2 simultaneously.
If <
BACKLIGHT> is set to
EXT : The interface to an external alarm enables an automatic switch between
DAY and NIGHT mode.
If you set
ALARM IN SET, the alarm can be used for an input signal in EXT mode of
If an alarm signal occurs, the mode will switch to NIGHT.
If <
DAY/NIGHT> is set to EXT, ALARM1 in ALARM OUT SET, and ALARM1 in ALARM
SET-AUTO SET are not available.
If you use an infrared light source while in AUTO mode, this may cause a failure in
AUTO SWITCH or AUTO FOCUS.
WhITe BAl
If you need to adjust the color according to the ambient illumination, you can use
the
For selecting and saving each menu item, refer to “How to use the keyboard controller”. (page 20)
Illumination is generally referred to as color temperature, which is represented in a
measurement of kelvin (K). Color temperatures for ordinary lighting are as follows:
In the
can set a mode for correcting the
BAL> menu to the change of the color temperature to correct the needed. The following color temperature ranges are assured in individual modes: ATW1 : 2500K ~ 9300K (1) ATW2 : 2000K ~ 10000K (suitable to sodium light source) (2) 1 : With < ATW1> mode active in a color temperature environment ranging beyond between 2500K and 9300K, a proper white balance value may not be produced; if this is the case, you are recommended to use 2 : With < ATW2> mode active in a mostly single color environment, the display color and the actual one may differ; so select a mode as appropriate to your color temperature environment. M Blue sky Rainy Cloudy Sunny Partly Cloudy Fluorescent lamp Halogen lamp Tungsten lamp Candlelight 10000K 9000K 8000K 7000K 6000K 5000K 4000K 3000K 2000K 1000K 00000A-EU2_SCC-C7455P-ENG.indb 29 2009-08-13 오후 9:54:14
- ATW1,2 : If you set the
