COLOR CCD CAMERA User Guide 8 COLOR CCD CAMERA User Guide 9
Do not drop the camera or
subject it to physical shock.
May cause a product malfunction.
Never keep the camera face to
strong light directly.
May damage the CCD.
Do not expose the camera to
radioactivity.
Radioactivity exposure may damage the
CCD.
• Exposure to a spotlight or an object emitting strong light may cause smear or
blooming.
• Ensure that the power source complies with normal specifications before supplying
it to the camera.
• In case of IR LED has been lighted, do not lighten directly eye.
Notes
Precautions Components and Accessories
Overview
❶ 2
FRONT
❶ Camera Sunshield
2 Sunshield adaptor : Fixing the sunshield onto the camera.
3 x12 Zoom Module
4 Front cover
5 Function Setup Switch :
Display the menu on the screen and move the cursor to four directions to confirm
status or after changing a selected item.
6 Video Output Terminal to Monitor :
Used for monitoring of video output When camera installation.
❶ SCO-2120R 2 Sunshield 3 L-type hexagon wrenches (3.0mm)
4 Sunshield Adaptor (1EA) 5 Tapping Screw (3EA) ❻ User Guide
➐ Installation Video Output Cable
❹ 3
➐ ❻
5
❶
4
5 6
2 3
