COLOR CCD CAMERA User Guide 36 COLOR CCD CAMERA User Guide 37
IMAGE ADJ : Includes image quality or special function factors.
- RET PKT : You can choose whether to send an ACK signal when the communication
control command is issued to the camera.
SPECIAL SETUP
PRIVACY OFF
DAY/NIGHT AUTO
DIS OFF
SYNC INT
COMM ADJ
IMAGE ADJ
MONITOR
CRT
When the SETUP menu screen is displayed, select ‘IMAGE ADJ.’ by moving the up or
down direction of the Function Setup Switch so that the arrow indicates 'IMAGE ADJ.
Select a desired mode by moving the up or down direction of the Function Setup
Switch.
- H-REV : You can flip the picture horizontally on the
screen.
- V-REV : You can flip the picture vertically on the screen.
IMAGE SETUP
▶ H-REV OFF
V-REV OFF
SHARPNESS ON
RETURN
SHARPNESS SETUP
▶ LEVEL 16
RETURN
|||||||||||||||||||| | |||||
Operating Your Camera
- LCD : Please select this menu item when using an LCD
monitor. LCD MONITOR SETUP
▶ GAMMA 0.45
PED LEVEL 17
COLOR LEVEL 50
RETURN
|||||||| | |||||||||||||||||
||||||||||||| | |||||||||
- CRT : Please select this menu item when using a CRT
monitor. CRT MONITOR SETUP
▶ PED LEVEL 17
COLOR LEVEL 50
RETURN
|||||||| | |||||||||||||||||
||||||||||||| | |||||||||
Monitor : Please change the settings value of video appropriate to your monitor.
SPECIAL SETUP
PRIVACY OFF
DAY/NIGHT AUTO
DIS OFF
SYNC INT
COMM ADJ
IMAGE ADJ
MONITOR
CRT
DISPLAY
- USER : Please use this menu item when using a monitor
other than standard ones. You can change the
gamma, PED level, and color gain in the sub
menus. USER MONITOR SETUP
▶ GAMMA 0.55
PED LEVEL 17
COLOR LEVEL 50
RETURN
|||||||| | |||||||||||||||||
||||||||||||| | |||||||||
- SHARPNESS : As you increase this value, the picture
outline becomes stronger and clearer.
• If use the sharpness level overly, the image comes out affectedly or appears image noise.
Notes
