COLOR CCD CAMERA User Guide 30 COLOR CCD CAMERA User Guide 31
Operating Your Camera
GAIN MANUAL SETUP
▶ AGC VAL 5dB
RETURN
SSNR3 LEVEL SETUP
▶ LEVEL 12
RETURN
• Image may become unstable if the camera is set to 'ESC' mode and faces a strong
fluorescent light.
• Under 'ESC' mode, the brightness can be adjusted by moving the left or right direction
of the Function Setup Switch.
Notes
AGC (Auto Gain Control) : For brighter images.
Position the indicator over 'AGC' by moving the up or down direction of the Function
Setup Switch.
Set 'AGC' to the desired mode by moving the left or right direction of the Function
Setup Switch.
- HIGH : Wide range gain value adjustment
- MANUAL : Selecting gain value range. (5dB ~ 41dB)
- OFF : Disabled
- LOW : Narrow range gain value adjustment
- MEDIUM : MEDIUM range gain value adjustment
SSNR3(Samsung Super Noise Reduction) : On screen noise reduction.
Position the indicator over 'SSNR3' by moving the up or down direction of the
Function Setup Switch.
Set 'SSNR3' to the desired mode by moving the left or
right direction of the Function Setup Switch.
- OFF : Disabled
EXPOSURE SETUP
BRIGHTNESS 50
IRIS AUTO
SHUTTER ---
AGC HIGH
SSNR3 ON
|||||||||||| | |||||||||||||
|||||||||||| | |||||||||||
• Changing the 'AGC' setting from LOW to HIGH results in greater sensitivity, as well as
on screen noise.
• Setting 'AGC' to OFF locks 'SSNR3' configuration.
Notes
SENS-UP : This feature ensures clear images at night or under low light conditions.
Position the indicator over 'SENS-UP' by moving the up
or down direction of the Function Setup Switch.
Set 'SENS-UP' to the desired mode by moving the left
or right direction of the Function Setup Switch.
- AUTO : Select this mode for use in night time or under
low light conditions.
- OFF : Disabled
SENS-UP LIMIT SETUP
▶ LIMIT X2
RETURN
• Once 'AUTO' mode is set, the user can configure the SENS-UP limit by increasing/
decreasing the shutter speed (e.g.: X2, X4....... X32, X64, X128, X256, X512).
• Enabling Sens-Up increases camera sensitivity and may result in additional noise and/
or other phenomenons. This is normal.
Notes
SPECIAL
MAIN SETUP
SSDR ON
WHITE BAL ATW
BACKLIGHT OFF
MOTION DET OFF
FOCUS
EXPOSURE
SPECIAL
RESET
