Samsung Digital Video Recorder SVR-1660C User Manual
Page 15
Install Manual
14
PLAY lamp
Lit when copying.
11
Power button
Turns on or off the device.
12
ESC button
The Escape button navigates up the menu tree and
closes dialog windows.
13
COPY
Starts Copy mode.
14 FUNC
Starts Function mode.
15
MONITOR
Cycles through from Monitor 1 to 4.
16
PTZ
Starts or ends PTZ function.
17
USB1, USB2
USB ports for external devices (mouse, USB memory
stick).
18
PLAY/ENTER
Start playback or select an item on the menu.
19
◀
/REW
Navigates or selects in the menu, or for playback,
changes the reverse playback speed.
20
▶
/FWD
Navigates or selects in the menu, or for playback,
changes the forward playback speed.
31
▲/PAUSE
Navigates or selects in the menu, or for playback,
pauses live or recorded video.
22
▼/STOP
Navigates or selects in the menu, or for playback, stops
playback.
