Reference diagram for snow-proof ducting – 1
Space requirements for setting – (1)
CHX03652/06052
Min. I Min. I
Min. M Mi
n
. N
Mi
n
. H
Mi
n
. J
(1) Single-unit installation
(2) Multiple-unit installation (2 or more units)
Top is open:
Top is blocked by an obstacle:
[Obstacle to the front of unit]
Outdoor unit
CHX03652/06052
A B D C E F G
5-29/32 5-29/32 7-7/8 11-13/16 11-13/16 5-29/32 7-7/8
Outdoor unit
CHX03652/06052
H I J
19-11/16 11-13/16 39-3/8
Outdoor unit
CHX03652/06052
K L
19-11/16 5-29/32
Outdoor unit
CHX03652/06052
M N
39-3/8 39-3/8
Min. C
Min. E
Min. F
Min. E Min. E
Min. L
Min. B
Mi
n
. A
Mi
n
. D
Mi
n
. K
Mi
n
. G
[Obstacle to the rear of unit]
(1) Single-unit installation
(3) Multiple-unit installation (2 or more units)
Top is open:
Note: In cases 2 and 3 the height of the obstacle
must be no taller than the height of the outdoor
unit.
Top is blocked by an obstacle:
(2) Obstacles on both sides
● ●
●
●
Unit: in.
