Shark VAC-THEN-STEAM MV2010 - Manual (Page 12)

8 TOLL FREE: 1-800-798-7398
3 Place the cleaning unit onto the
Steam Frame. THE UNIT MUST BE
UPRIGHT.
IMPORTANT: Steam frame and pad
must be attached to the cleaning unit
in order to use the steam function.
Steam Mode
ASSEMBLY
1 Attach a steam pad onto the bottom
of the steam frame, matching the
hook and loop fasteners.
2 Place the steam frame/pad assembly
on the floor with the magnetic
connections facing up.
1
3
2
MAGNETIC
CONNECTIONS
MV2010_11_IB_ENG_110103.indd 8 11-01-03 1:26 PM
