English
EMPTYING THE DUST CUP
1 Press the dust cup latch at the
bottom of the canister upward. Pull
the dust cup assembly out and down.
2 Twist dust cup cover counter-
clockwise to open.
3 Tap canister gently over trash
receptacle to empty.
EMPTYING THE CONE FILTER
Over time the debris may gather in
the cone filter of your
Vac-Then-
Steam™. Clean the filter often for
optimal suction performance.
1 Lift the filter frame out from the top
of the dust cup and remove the two
filter layers from the filter frame.
2 Tap filter canister gently over trash
receptacle to empty debris from the
conical filter.
Reattach the filter frame.
3 To reattach the dust cup cover, align
the indicators that are printed on the
rear of the dust cup and cover. Turn
the cover clockwise and make sure
the solid arrows are aligned before
reinserting the dust cup into the
vacuum.
4 To replace the dust cup in to the unit,
gently push the dust cup assembly
up and in. The dust cup will click
into place.
1
1
2
2
3
3
4
EMPTYING THE DUST CUP
EMPTYING THE CONE FILTER
