Scag Power Equipment SSZ - Manual (Page 27)

23
Ref. Part
No. Number Description
48 52 61
HYDRAULIC COMPONENTS
1 04030-03 Lockwasher, 5/16" X X X
2 04040-04 Flatwasher, 5/16" (.344 x .688 x .065) X X X
3 04017-05 Bolt, 1/4-20 x 3/4" Serrated Flange Hex Hd. X X X
4 48790 Pulley, Pump X X X
5 48791 Tapered Hub, 15mm Bore X X X
6 48789 Fan X X X
7 421209 Washer, Back-up X X X
8 04050-13 Snap Ring X X X
9 04017-04 Bolt, 1/4-20 x 1/2" Serrated Flange Hex Hd. X X X
10 04063-14 Key, 5mm x 25mm X X X
11 04001-12 Bolt, 5/16-18 x 1-3/4"Hex Head X X X
12 04001-96 Bolt, 5/16-18 x 4-1/2" Hex Head X X X
13 04001-95 Bolt, 5/16-18 x 5" Hex Head X X X
14 04001-94 Bolt, 5/16-18 x 7-1/2" Hex Head X X X
15 04020-03 Nut, 5/16-18 X X X
16 04001-30 Bolt, 3/8-16 x 4" Hex Head X X X
17 48878 Spacer X X X
18 48875 Gear X X X
19 04019-04 Nut, 3/8-16 Serrated Flange Hex Head X X X
20 48784 Pump, LH (includes Spacer) X X X
20A 48785 Pump, RH (Includes Spacers) X X X
21 481097 Axle, LH (Includes Brake Lever) X X X
21A 481098 Axle, RH (Includes Brake Lever) X X X
22 48350-09 Elbow, 90 Degree X X X
23 48860 Oil Tank Reservoir X X X
24 48894 Cap, Oil Reservoir X X X
25 421208 Strap, Oil Reservoir X X X
26 04001-59 Bolt, Hex Head 1/4-20 x 1-1/4" X X X
27 04021-08 Nut, Elastic Stop 1/4-20 X X X
28 48485-01 Elbow, 90 Degree X X X
29 48603-06 "O" Ring, .5/64 x 15/32 ID X X X
30 48872 Hose Assembl, Filter Inlet X X X
31 48604-02 Plug, 3/4-16 "O" Ring X X X
32 48462-02 Head, Oil Filter X X X
33 48462-01 Oil Filter, Special X X X
34 48871 Hose Assembly X X X
35 48603-04 "O" Ring, 3/32 x 3/4 ID X X X
36 48603-03 "O" Ring, 1/16 x 3/8 ID X X X
37 48810-01 1/2" T-Fitting X X X
38 48603-02 "O" Ring, 3/32 x 5/8 ID X X X
39 48572-02 Tube Union X X X
40 48350-10 Elbow, 90 Degree X X X
41 481090 Gasket, Hydraulic Tank Cap X X X
42 48603-07 "O" Ring
* Common hardware which should be purchased locally. All bolts Grade 5 plated, all other fasteners zinc plated.
** Contact engine manufacturer for replacement engine.
