19
1 45524 Bellcrank, Lift - Right Front X X X
2 48100-05 Bushing X X X
3 45527 Lift Link X X X
4 43180 Bushing X X
5 04050-01 Retaining Ring, 5/8" External “E” X X
6 45610 Lift Arm Weldment X
45523 Lift Arm Weldment X X
7 04017-17 Bolt, Serrated Flange Hex Head 5/16-18 x 1" X X X
8 46384 Height Adjustment Lever (Includes grip) X X X
9 48093 Grip, Lever Lift X X X
10 44065 Rod, Cutter Deck Lock X X X
11 48053 Spring, Deck Lift Index X X X
12 04060-01 Roll Pin, 5/32 x 3/4" X X
13 42887 Lock, Rod Guide X X X
14 04019-04 Nut, Serrated Flange Hex 3/8-16 X X X
15 04019-03 Nut, Serrated Flange Hex 5/16-18 X X
16 48114-04 Grease Fitting X X X
17 04017-05 Bolt, Serrated Flange Hex Head 1/4-20 x 3/4" X X
18 42828 Strip, Height Adjustment X X X
19 04019-02 Nut, Serrated Flange Hex 1/4-20 X X
20 04041-08S Flatwasher, 3/4" (.766 x 1.250 x.075) X X
21 04050-02 Ring, Retaining 3/4" External “E” X X
22 04021-09 Nut, Elastic Stop 3/8-16 X X X
23 04040-09 Flatwasher, 5/8" (.656 x 1.312 x .075) X X X
24 45313 Bellcrank, Lift - Left Front X X X
25 43271 Swivel Joint - LH THD X X X
26 04004-18 Adjustment Stud X
04004-15 Adjustment Stud X X
27 04040-10 Flatwasher, 5/8" (.688 x 1.75 x .134) X X X
28 48540 Chain X X
29 04001-20 Bolt, Hex Head 3/8-16 x 1-1/2" X X X
30 04020-09 Nut, Hex 5/8-11 X X X
31 43270 Swivel Joint - RH X X X
32 481045 Spring, Deck Lift X
32 48953 Spring, Deck Lift X X
33 45427 Bellcrank X X X
34 04063-15 Key, 3/16 x 3/16 x .75" X X X
35 48114-05 Grease Fitting X X
36 421585 Link, Deck Support X
37 04001-45 Bolt, Hex Head 3/8-16 x 2" X X X
* Common hardware which should be purchased locally. All bolts Grade 5 plated, all other fasteners zinc plated.
Ref. Part 48 52 61
No. Number Description
CUTTER DECK CONTROLS 48", 52", & 61" DECKS
