21
1 48100-08 Bushing X X X
2 48114-04 Grease Fitting X X X
3 43257 Bushing, Spring Keeper X X X
4 04062-02 Hair Pin, .08 Diameter x 1-3/16" X X X
5 04041-07 Flatwasher, 3/8" (.391 x .738 x .105) X X X
6 44062 Rod, Foot Plate Latch X X X
7 481086 Cable, Seat Stop X X X
8 421589 Foot Plate X
42764 Foot Plate X X
9 481049 Hinge X X X
10 04003-12 Bolt, Carriage 5/16-18 x 3/4" X X X
11 04001-08 Bolt, Serrated Flange Hex
Head 5/16-18 x 3/4" X X X
12 421251 Kick Plate X X X
13 48746 Neutral Return Spring X X X
14 04021-10 Nut, Elastic Stop 5/16-18 X X X
15 46505 Fender Assembly, RH (with decal) X X X
16 04001-73 Bolt, Hex Head 5/16-18 x 3-3/4" X X X
17 04003-04 Bolt, Carriage 5/16-18 x 1" X X X
18 421411 Retainer, Neutral Spring, LH X X X
18A 421412 Retainer, Neutral Spring, RH X X X
19 45405 Seat Switch Bracket X X X
20 48463 Spring X X X
21 04064-04 Clevis Pin X X X
22 04017-15 Bolt, Serrated Flange Hex
Head 5/16-18 x 1/2" X X X
23 04062-02 Hair Pin, Cotter X X X
24 48831 Seat Assembly X
48930 Seat Assembly w/Adjuster Rails X X
25 04019-03 Nut, Serrated Flange Hex 5/16-18 X X X
26 45599 Seat Base X X X
27 04021-08 Nut, Elastic Stop 1/4-20 X X X
28 04021-09 Nut, Elastic Stop 3/8-16 X X X
29 04019-02 Nut, Serrated Flange Hex 1/4-20 X X X
30 04017-06 Bolt, Serrated Flange Hex Head 1/4-20 x 1" X X X
31 04001-31 Bolt, Hex Head 3/8-16 x 2-1/2" X X X
32 04001-15 Flatwasher, 5/16" (.313 x .875 x .083) X X X
33 48686 Seat Spring X X X
Ref. Part
No. Number Description
48 52 61
Ref. Part
No. Number Description
48 52 61
34 421198 Fender Panel, LH X X X
35 48566 Cable, Seat Stop X X X
36 48464 Ball Joint, Neutral X X X
37 45479 Fender , LH X X X
38 46392 Caster Wheel Yoke Assembly X X X
39 04066-01 Quick Pin X X X
40 45325 Caster Wheel Yoke X X X
41 04021-07 Nut, Elastic Stop 1/2-13 X X X
42 43041 Spacer X X X
43 04001-80 Bolt, Hex Head 1/2-13 x 6-1/2" X X X
44 48537 Wheel Assembly, Complete X X X
45 48006-07 Retainer X X X
46 48537-02 Tire Only X X X
47 48537-03 Rim Only X X X
48 43022 Sleeve X X X
49 48006-06 Roller Bearing X X X
50 48717 Seat Switch X X X
51 48704-02 Seat, Back Cushion X X X
52 48704-03 Seat, Bottom Cushion X X X
53 48704-04 Arm Pad, RH X X X
54 48704-05 Arm Pad, LH X X X
55 48522 Neutral Interlock Switch X X X
56 421253 Neutral Lock Bracket, RH X X X
56A 421252 Neutral Lock Bracket, LH X X X
57 04017-24 Bolt, Serrated Flange Hex
Head 5/16-18 x 2-3/4" X X X
58 43240 Spacer, Neutral Spring X X X
59 43258 Spacer, Neutral Lock Bracket X X X
60 04020-14 Nut, Hex 3/8-24 UNF X X X
61 48704-06 Bolt, Hex Head w/Washer, 1/4-20 x 3/4" X X X
62 04001-99 Bolt, Hex Head 3/8-24 x 6-1/2", UNF X X X
63 48931 Seat Adjustment, Track Set X X X
64 48030-09 Cable Clamp, .50 ID X X X
65 04001-09 Bolt, Hex Head 5/16-18 x 1" X X X
66 04017-16 Bolt, Serrated Flange Hex Head 5/16-18 x 1" X
67 * Bolt, Hex Head 1/4-20 x 1.25" X X X
68 * Lockwasher, 5/16" X X X
* Common hardware which should be purchased locally. All bolts Grade 5 plated, all other fasteners zinc plated.
SHEET METAL COMPONENTS
