48", 52", & 61" CUTTER DECKS
1 46756 Cutter Deck (Includes decals) X
46615 Cutter Deck (Includes decals) X
46611 Cutter Deck (Includes decals) X
2 421058 Belt Cover, Front X
421451 Belt Cover, Front X
421299 Belt Cover, Front X
3 04041-07 Flatwasher, 3/8" Special (.391 x .938 x .105) X X X
4 04029-03 Wing Nut, 3/8-16 X X X
5 48584 Anti-Scalp Wheel X X X
6 04001-79 Bolt, Hex Head 5/8-11 x 4-1/2" X X X
7 42882 Anti-Scalp Wheel Bracket X X X
8 04017-27 Bolt, Hex Serrated Flange 3/8-16 x 1" X X X
9 04040-10 Flatwasher, 5/8" (.688 x 1.75 x .134) X X X
10 04021-13 Nut, Hex Elastic Stop 5/8-11 X X X
11 46727 Discharge Chute X X
46728 Discharge Chute X
12 04001-09 Bolt, Hex Head 5/16-18 x 1" X X X
13 04021-10 Nut, Hex Elastic Stop 5/16-18 X X X
14 04017-16 Bolt, Hex Serrated Flange 5/16-18 x 3/4" X X X
15 44078 “J” Rod X
44101 “J” Rod X X
16 45037 Idler Pivot Base X X X
17 04001-46 Bolt, Hex Head 3/8-16 x 2-1/4" X X X
18 48100-05 Bushing X X X
19 481035 Nut, Special 1-1/16-18 X X X
20 04019-03 Nut, Hex Serrated Flange 5/16-18 X X X
21 46081 Idler Arm (Includes bushings &
grease fittings) X X X
22 43077 Spacer X X X
23 43028 “J” Rod X X
44078 “J” Rod X
24 04021-09 Nut, Hex Elastic Stop 3/8-16 X X X
25 48114-04 Grease Fitting X X X
26 04041-08 Flatwasher, 3/4" X X X
04041-08S Flatwasher, 3/4" Special X X X
27 04050-02 Ring, Retaining 3/4" External “E” X X X
28 48181 Pulley, Idler X X X
29 43297 Spindle Bushing, Bottom X X X
30 48924 Pulley, LH Spindle X X
48753 Pulley, LH Spindle X
31 48926 Tapered Hub, 1-1/8 Bore X X X
32 04001-01 Bolt, Hex Head 1/4-20 x 3/4" X X X
33 04001-41 Bolt, Hex Head 5/8-11 x 9-1/2" X X X
34 48087 Belt, RH Blade Drive X
48285 Belt, RH Blade Drive X
48265 Belt, RH Blade Drive X
35 04001-23 Bolt, Hex Head 3/8-16 x 4-1/2" X X X
36 48550 Pulley, Idler Cutter Engagement X X X
37 48923 Pulley, Double Groove X X
48940 Pulley, Double Groove X
Ref. Part
No. Number Description
48 52 61
38 48799 Belt, Blade Drive X
481001 Belt, Blade Drive X
48996 Belt, Blade Drive X
39 04041-12 Flatwasher, 3/8" (.375 x 1.5 x .06) X X X
40 48807 Spring, Idler Tension X X X
41 48100-02 Bushing X X X
42 46749 Idler Arm (Includes bushings &
grease fittings) X
46750 Idler Arm (Includes bushings &
grease fittings) X X
43 45329 Idler Pivot Base X X X
44 04001-97 Bolt, Hex Head 5/8-11 x 3" X X X
45 43282 Spacer X X
46 04020-16 Nut, Hex 5/8-18 UNF X X X
47 48763 Rod End X X X
48 46460 Push Arm (Includes 25, 46, 47, and 49) X X X
49 48100-06 Bushing X X X
50 45332 Push Arm Shaft X X X
51 46631 Spindle Assembly X X X
52 43298 Spindle Shaft X X X
53 481024 Seal, Top X X X
54 481022 Bearing Assembly (1 required per spindle) X X X
55 48667 Relief Fitting, Tapered Spindle X X X
56 43294 Spindle Housing X X X
57 481025 Seal, Bottom X X X
58 43312 Spacer, Outside X X X
59 43296 Spacer, Inside X X X
60 04063-08 Key, 1/4 x 1/4 x 2" X X X
61 04001-10 Bolt, Hex Head 5/16-18 x 1-1/4" X X X
62 43279 Spacer, Tapered Spindle X X X
63 48110 Cutter Blade, 16-1/2" Standard X
48184 Cutter Blade, 16-1/2" High Lift X
48108 Cutter Blade, 18" Standard X
48185 Cutter Blade, 18" High Lift X
48111 Cutter Blade, 21" Standard X
48304 Cutter Blade, 21" High Lift X
64 481050 Spring, Discharge Chute X X X
65 48786 Electric Clutch X X X
66 04001-108 Bolt, Hex Head 5/16-18 x 4.25" X X X
67 421616 Belt Cover, LH X
421615 Belt Cover, RH X
42889 Belt Cover, LH X
42890 Belt Cover, RH X
42892 Belt Cover, LH X
42893 Belt Cover, RH X
68 48924 Pulley, RH Spindle X X X
69 04001-109 Bolt, Hex Head 1/4-20 x 1.375 Full Thread X X X
70 * Nut, Hex 5/8-11 UNC X X X
71 04050-05 Ring, Retaining 1-1/8" External “E” X X X
