Samsung CLP-600 - Manual (Page 69)

Installing Printer Options
9.4
8
Insert the two screws included with the interface card
package into the appropriate holes above and below the
Ethernet network port, as shown below. Carefully tighten
them.
9
Insert the antenna counter clockwise and flip it upright, as
shown.
10
Replace the metal cover, as shown below, and replace the
four screws you removed in step 4.
11
Replace the control board cover, as shown below, and
replace the four screws you removed in step 2.
12
Plug one end of the Ethernet cable into the Ethernet
network port on the printer and the other end of the cable
into a network LAN connection.
N OTE : For information about configuring and using the printer
in both wired and wireless network environments, refer to the
Network Printer User’s Guide provided with the wired/wireless
network interface card. You can also configure the network
parameters on the control panel; see page 8.4.
