Section 8

REPLACEMENT DECALS AND INFORMATION PLATES

Ref.
No.

Part No.

Description

1

483405

Decal, Discharge Chute

2

48314

Decal, Scag Logo

3

483407

Decal, Danger-Spinning Blades

4

483406

Decal, Warning-Rotating Blades

5

483044

Decal, Patents

6

48404

Decal, Metalcraft - Made in USA

7

483441

Decal, Instrument Panel - Rear

8

483404

Decal, Sulky Attachment

9

483402

Decal, Belt Cover

10

481423

Decal, Instrument Panel - Front (SWZ-19KAI & SWZ-21KAE only)

11

481483

Decal, Instrument Panel - Front

12

482297

Decal, 36 Advantage

13

483199

Decal, 48 Velocity Plus

483200

Decal, 52 Velocity Plus

483201

Decal, 61 Velocity Plis

14

481971

Decal, Heavy Duty Commercial

15

481124

Decal, Speed Control

16

481942

Decal, Scag Zero Turn

17

481425

Decal, Oil

18

482799

Decal, Tracking Adjustment

19

482816

Decal, Height of Cut

**

461986

Spanish Decal Kit, Walk-Behinds (Not Shown)

482816

CUTTING HEIGHT ADJUSTMENT

TOP

MIDDLE

MIDDLE

BOTTOM

BOTTOM

BOTTOM

NUMBER OF SPACERS ABOVE CUTTER BLADES

0 1 2 3 4 5

0

0

1

2

3

4

-

-

-

-

-

4-3/8

-

-

-

-

4

4-1/8

2-3/8

2-5/8

2-3/4

-

3-3/4

3-7/8

2-1/8

2-3/8

2-1/2

-

3-1/2

3-5/8

1-7/8

2-1/8

2-1/4

2-7/8

3-1/4

3-3/8

1-5/8

1-7/8

2

2-5/8

3

3-1/8

DECK MOUNTING HOLE POSITION

NUMBER OF CASTER SPACERS (BELOW SUPPORT)

16

19

18

SEE

OPERATOR’S

MANUAL

OIL

17
