54
R
Section 8
HANDLE WIRE HARNESS -
MANUAL START
PART NO. 482686
SWZ2003WH482686
SW08WH483075
WIRE HARNESS
ADAPTER - ENGINE
BLADE
CLUTCH
GROUND
BLACK
KOHLER
(15 HP)
ENGINE DECK
WIRE HARNESS
PART NO. 483075
E A
F B
G C
H D
INSTRUMENT
PANEL HARNESS
BLACK
BLUE
WHITE
WHITE
YELLOW
NEUTRAL
INTERLOCK
BLA
CK
W/RED STRIPE
BLACK W/RED STRIPE
WHITE
KAWASAKI
(15 HP, 16 HP & 17 HP)
WIRE HARNESSES
