English _51
●
SETUP SCREEN
Target bitrate : Transfers video signal at a specifi ed bit rate.
Compression : Adjust the compression rate from 5 through 100 by 5.
Encode priority : Set the video transfer method to Frame rate or Quality.
GOP* size : Select a GOP size between 5 and 15.
Deblock : This will soften the edges between macro blocks.
De-Interlace : You can reduce the grid noise by using the de-interlacing function.
Only available if MPEG4 resolution is set to 4CIF.
If the WDR is set to or the MPEG4 resolution is not 4CIF, you cannot enable the
MPEG4 CODEC’s de-interlacing
Profile : Select Baseline or Main for the H.264 profiling method.
Entropy coding* : Reduces the compression loss due to encoding.
If you set the profi le to Baseline, the entropy coding is available only for CAVLC*; if you set it
to MAIN, the entropy coding is available for both CAVLC* and CABAC*.
Motion estimation : Estimates the movement of pixels by determining the motion vector.
Input gain : You can set the audio input gain from 0 to 10.
Output gain : You can set the audio output gain from 0 to 10.
If the audio input gain is set to 0, no sound is heard.
When done, click [Apply].
Your settings will be saved.
To configure the IP settings
Select <Basic> - <IP>.
The IP setup window appears.
IP confi guration : Set the IP and port
settings for the camera.
IP type : Select one from <Static
IP>, <Dynamic IP>, and <PPPoE
IP>.
If you select , you can
provide the optional ADSL IP and
password. However, the multicast items
(multicast address, port, TTL) for VNP
and RTP will disappear.
