Installation & connection – Samsung SNC-B2335P User Manual
Page 20
installation & connection
20_ installation & connection
Audio I/O Block Diagram
Audio Codec
G.711 PCM. µ-law 64kbps 8kHz sampling
Full duplex Audio
Audio in
Used for mono signal line input (Max.2.4 Vpp)
Audio out
Used for mono signal line output (Max.2.4 Vpp)
Line out impedance
600
y
y
y
y
y
Speaker
Pre-Amp
Microphone
PC
Pre-Amp
Microphone
Network
