27.1.1999
Xo0236e4_fm5.fm 19
Product: DB-40 (Branching Unit) / OO0241
9.2.4 Parts list OO0241
OO0241
CODE PART DESCRIPT. VALUE MANUF. TYPE
CH0105 C201 SMD capasitor 1uF/-20/+80%/16V TaiyoYuden EMK212 F105Z00T
CH0105 C202 SMD capasitor 1uF/-20/+80%/16V TaiyoYuden EMK212 F105Z00T
CH0105 C203 SMD capasitor 1uF/-20/+80%/16V TaiyoYuden EMK212 F105Z00T
CH0105 C204 SMD capasitor 1uF/-20/+80%/16V TaiyoYuden EMK212 F105Z00T
CH0105 C205 SMD capasitor 1uF/-20/+80%/16V TaiyoYuden EMK212 F105Z00T
CH0105 C206 SMD capasitor 1uF/-20/+80%/16V TaiyoYuden EMK212 F105Z00T
CH0105 C207 SMD capasitor 1uF/-20/+80%/16V TaiyoYuden EMK212 F105Z00T
CD0180 C208 SMD capasitor 18 pF 5% 50 V NPO Philips
CD0180 C209 SMD capasitor 18 pF 5% 50 V NPO Philips
CD0180 C210 SMD capasitor 18 pF 5% 50 V NPO Philips
DZ0519 D201 SMD zener 5V1 5% 300mW Philips BZX84C5V1
VM0242 HS SMD system connector 1x16 pin AMP 188227-1
IC0453 I201 SMD 2x multip./demultip. Toshiba TC4W53F-TE 12L
IC0453 I202 SMD 2x multip./demultip. Toshiba TC4W53F-TE 12L
PO0241 M200 PCB for juction box 60x40mm FR4 Metalex
NC2005 M201 Cross recessed screw M2x5 SFS2977 DIN9652 Ruuvitalo Pozidriv
NC2005 M202 Cross recessed screw M2x5 SFS2977 DIN9652 Ruuvitalo Pozidriv
NC2005 M203 Cross recessed screw M2x5 SFS2977 DIN9652 Ruuvitalo Pozidriv
NC2005 M204 Cross recessed screw M2x5 SFS2977 DIN9652 Ruuvitalo Pozidriv
NF0200 M205 Nut M2 SFS2067 / DIN943 Ruuvitalo
NF0200 M206 Nut M2 SFS2067 / DIN943 Ruuvitalo
NF0200 M207 Nut M2 SFS2067 / DIN943 Ruuvitalo
NF0200 M208 Nut M2 SFS2067 / DIN943 Ruuvitalo
VM0242 PC SMD system connector 1x16 pin AMP 188227-1
VM0116 PC/HS Contact strip angle 2x8 NB-electr. H4-6-16G
RD0103 R201 SMD resistor 10 k 5% 0.125 W Kamaya
RD0103 R202 SMD resistor 10 k 5% 0.125 W Kamaya
RD0103 R203 SMD resistor 10 k 5% 0.125 W Kamaya
RD0103 R204 SMD resistor 10 k 5% 0.125 W Kamaya
RD0102 R205 SMD resistor 1 k 5% 0.125 W Kamaya
Last
update
12.12.94
