27.1.1999
4Y0725GB 46
Product: TDP-52-SN3 (Sigma Gold) / OY0725-RF
CF0101 C611 SMD capasitor 100 pF 5% 50 V NP0 Philips
CF0569 C612 SMD capasitor 5.6 pF/0.25pF 50 V NP0 Philips
CF0222 C620 SMD capasitor 2.2 nF 5% 50 V NP0 Philips
CF0332 C621 SMD capasitor 3.3 nF 5% 50 V NP0 Philips
CU2105 C622 SMD tantal 1uF/10V AVX TAJR105M010R
CF0102 C631 SMD capasitor 1 nF 5 % NP0 Philips
CU0225 C632 SMD tantal 2.2uF/16V 20% 4.7x2.6mm Matsushita ECST1CB 225R
CF0102 C633 SMD capasitor 1 nF 5 % NP0 Philips
CF0101 C640 SMD capasitor 100 pF 5% 50 V NP0 Philips
CF0101 C641 SMD capasitor 100 pF 5% 50 V NP0 Philips
CF0101 C642 SMD capasitor 100 pF 5% 50 V NP0 Philips
CF0229 C650 SMD capasitor 2.2pF +-0.25pF 50V NPO Philips
CF0221 C660 SMD capasitor 220 pF 5% 50 V NP0 Philips
CF0221 C661 SMD capasitor 220 pF 5% 50 V NP0 Philips
CF0221 C662 SMD capasitor 220 pF 5% 50 V NP0 Philips
CF0102 C663 SMD capasitor 1 nF 5 % NP0 Philips
CF0102 C664 SMD capasitor 1 nF 5 % NP0 Philips
CF0102 C665 SMD capasitor 1 nF 5 % NP0 Philips
CF0102 C666 SMD capasitor 1 nF 5 % NP0 Philips
CF0221 C667 SMD capasitor 220 pF 5% 50 V NP0 Philips
CF0103 C668 SMD capasitor 10 nF 10% 50 V X7R Philips
CF0102 C670 SMD capasitor 1 nF 5 % NP0 Philips
CF0102 C671 SMD capasitor 1 nF 5 % NP0 Philips
CF0102 C672 SMD capasitor 1 nF 5 % NP0 Philips
CF0102 C673 SMD capasitor 1 nF 5 % NP0 Philips
CF0153 C674 SMD capasitor 15nF 10% 50V X7R Philips
DC0229 D301 SMD silicon tuning diode 1V/19pF...4V/11pF Toshiba 1SV229
DC0229 D401 SMD silicon tuning diode 1V/19pF...4V/11pF Toshiba 1SV229
DP0132 D600 SMD pin diode Hitachi HVC132
DY0062 D610 SMD shcottky diode 40V 20mA Siemens BAT 62
IV6070 I201 FM IF-system Philips SA607DK
IS2335 I300 Dual freg.synthesizer PLL+prescaler 1.2GHz NationalSe LMX23352TMX
IR1248 I380 Regulator 4.8V/240mA +-2,4% Toko TK11248AM
IR1248 I480 Regulator 4.8V/240mA +-2,4% Toko TK11248AM
IR1248 I601 Regulator 4.8V/240mA +-2,4% Toko TK11248AM
IA7550 I610 Single op.amp. Toshiba TA 75S01F-TE85L
IW8710 I620 RF-power amplifier 430-460 MHz Mitsubishi M68710H
LC3392 L101 SMD inductor 3n9 -+2% Panasonic ELJRE3N9ZF2
LC3123 L102 SMD inductor 12n -+2% PANA-
SONIC
ELJRE12NGF2
LC3334 L103 SMD inductor 330nH +-10% TDK MLF1608DR33K
LC2334 L104 SMD inductor 330 nH/+-10% TDK MLF2012DR33KT
LC3223 L105 SMD inductor 22n -+2% Panasonic ELJRE22NGF2
LC3472 L106 SMD inductor 4n7 -+2% Panasonic ELJRE4N7ZF2
LC2334 L201 SMD inductor 330 nH/+-10% TDK MLF2012DR33KT
LC2104 L202 SMD inductor 100 nH/+-10% TDK MLF2012DR10KT
LI0450 L203 SMD Quad. coil 450kHz Sagami 950997404
LC2224 L204 SMD inductor 220 nH/+-10% TDK MLF2012DR22KT
LC1224 L301 SMD inductor 220 nH/+-10% Coilcraft 0805CS-221XKBC
LC1224 L401 SMD inductor 220 nH/+-10% Coilcraft 0805CS-221XKBC
LC3183 L430 SMD inductor 18n -+2% PANA-
SONIC
ELJRE18NGF2
PY0700 PCB1 PCB for OY0720 Irlandus
QFB739 Q101 GaAs MES FET 2 GHz 240mW N1.8dB/1.75GHz Siemens CF 739 B
QFB739 Q102 GaAs MES FET 2 GHz 240mW N1.8dB/1.75GHz Siemens CF 739 B
QAA193 Q201 SMD RF-transistor 6GHz/300mW F=1.9dB Philips BFR93AW
QA4995 Q301 SMD RF transistor NPN 11GHZ 16dB/900MHz Hitachi 2SC4995
QA4995 Q320 SMD RF transistor NPN 11GHZ 16dB/900MHz Hitachi 2SC4995
QAA193 Q360 SMD RF-transistor 6GHz/300mW F=1.9dB Philips BFR93AW
QA4995 Q410 SMD RF transistor NPN 11GHZ 16dB/900MHz Hitachi 2SC4995
CODE PART DESCRIPT. VALUE MANUF. TYPE
