SIGMA BENEFON TDP-52-SN3 - Manual (Page 22)

27.1.1999
6DP_52GB 7
Product: TDP-52-SN3 /
A Diagram of Connections
87
87A
86 85
30
+VB
Horn
External Alert
86
85
87A 87
30 87
87A
86 85
30
MUTE
+ACC
Car Radio
Supply Voltage
+VB
Battery Voltage
86
85
87A 87
30
PIN Name Color
1 Car Radio Mute (active low) Blue
2 Hf Speaker Grey
3 Ground - Black
4 External Alert (active low) Brown
5 Hf Speaker Grey
6 Vbatt, +12/24 V Red
External Alert Car Radio Mute (See the installation
instructions of your car radio)
UDH-50
KDS-50
HDS-50
Vb
att
, +
12
/24
V Car Radio
External
Alert
Mute
Installation
base
Installation
base
fuse
open
Hf Speaker
+ACC: to the +12 V power terminal
which is energized in the accessory
position of the ignition key
+VB
External Alert
Horn
Microphone
How to install a
cable to a carbox.
to KDS-50
