27.1.1999
4H0700GB.__2 32
Product: TDP-52-SN3 (Sigma Gold) / OH0700
AS0115 S132 Switch with LED Citizen LS5J2M-1YG-T
AS0115 S133 Switch with LED Citizen LS5J2M-1YG-T
AS0115 S134 Switch with LED Citizen LS5J2M-1YG-T
AS0115 S135 Switch with LED Citizen LS5J2M-1YG-T
AS0115 S136 Switch with LED Citizen LS5J2M-1YG-T
AS0115 S137 Switch with LED Citizen LS5J2M-1YG-T
CF0221 T100 SMD capasitor 220 pF 5% 50 V NP0 Philips
CF0223 T101 SMD capasitor 22 nF 10% 50 V X7R Philips
CF0221 T102 SMD capasitor 220 pF 5% 50 V NP0 Philips
CF0221 T103 SMD capasitor 220 pF 5% 50 V NP0 Philips
CF0221 T104 SMD capasitor 220 pF 5% 50 V NP0 Philips
CF0221 T105 SMD capasitor 220 pF 5% 50 V NP0 Philips
CF0221 T106 SMD capasitor 220 pF 5% 50 V NP0 Philips
CF0221 T107 SMD capasitor 220 pF 5% 50 V NP0 Philips
CF0221 T108 SMD capasitor 220 pF 5% 50 V NP0 Philips
CF0221 T109 SMD capasitor 220 pF 5% 50 V NP0 Philips
CF0221 T110 SMD capasitor 220 pF 5% 50 V NP0 Philips
CF0221 T111 SMD capasitor 220 pF 5% 50 V NP0 Philips
VM0242 V100 SMD system connector 1x16 pin AMP 188227-1
VM0017 V101 SMD B/B-connector 2x20 pin JAE IL312-40PB-VF30
VP0009 V102 Battery connector 3 pin SMC 972396
LF0061 X100 SMD EMI suppression filt 4700pF/2A 1.6x6.8mm Murata NFM61R30T472
LF0061 X101 SMD EMI suppression filt 4700pF/2A 1.6x6.8mm Murata NFM61R30T472
PH0700 Y10 PCB for OH0700 49,8x82,3mm 4-layer
Last
update
30.01.97
CODE PART DESCRIPT. VALUE MANUF. TYPE
