Product: UDH-50 (Carbox) / OW0700
DT0033
D100
SMD Transil
33V71500W
SGS-
Thomso
SM15T33A
DZ0180
D200
SMD zener
18V 5% 300mW
Philips
BZX84C18
DT0033
D230
SMD Transil
33V71500W
SGS-
Thomso
SM15T33A
DT0033
D240
SMD Transil
33V71500W
SGS-
Thomso
SM15T33A
DS0056
D510
SMD diode pair
70V/100mA common anode
Philips
BAW 56
DS0056
D511
SMD diode pair
70V/100mA common anode
Philips
BAW 56
DY0045
D530
Shottky diode
45V/10A
I&R
10TQ045
DS0099
D531
SMD diode
70 V 200 mA
Philips
BAV 99
DZ1569
D532
SMD zener
5V6 2% 300mW
Philips
BZX84B5V6
DT0010
D533
SMD Trans zorb
10V/35A/600W
Motorola
1SMB10AT3
IR1317
I200
Adjustable regulator
1.2-37V 1.5A
National S
LM317AT
IR2951
I210
Regulator
100mA 5V adj. 5%
National
LP2951CM
II8574
I220
8 bit I/O
I2C
Philips
PCF8574T
IA7550
I300
Single op.amp.
Toshiba
TA 75S01F-TE85L
IC0453
I320
SMD 2x multip./demultip.
Toshiba
TC4W53F-TE 12L
IA7550
I321
Single op.amp.
Toshiba
TA 75S01F-TE85L
IC0453
I322
SMD 2x multip./demultip.
Toshiba
TC4W53F-TE 12L
IA7550
I330
Single op.amp.
Toshiba
TA 75S01F-TE85L
IA1905
I410
Audio power amplifier
5W/20V/4ohm
SGS/
Thomso
TDA1905
IC0453
I430
SMD 2x multip./demultip.
Toshiba
TC4W53F-TE 12L
IC0453
I431
SMD 2x multip./demultip.
Toshiba
TC4W53F-TE 12L
IA7550
I440
Single op.amp.
Toshiba
TA 75S01F-TE85L
IA1905
I460
Audio power amplifier
5W/20V/4ohm
SGS/
Thomso
TDA1905
IX0555
I520
Timer
Pipolar
Philips
SA555D
IO0172
I521
Optocoupler
Siemens
CNY17-2
IA2902
I540
Low power quar op-amp.
NationalSe
LM2902M
LA3117
L100
Inductor
110uH 3A R=0.07ohm
Fuji
SL03B111BE
LA1391
L501
Choke horizintal
90uH +-10%
Trafocomp
TJ1391
LA1391
L530
Choke horizintal
90uH +-10%
Trafocomp
TJ1391
PW0700
PCB1
PCB for carbox
Aspocomp
QF9024
Q200
SMD p-channel FET
60V 9A Rds=0.28
I&R
IRFR9024TR
QF7002
Q201
SMD n-channel FET
60V 0.115A Rds7.5
Siliconix
2N7002-T1
QSB858
Q230
SMD transistor
PNP 0.1A/30V F<10dB
Philips
BC 858 B
QS1054
Q231
SMD transistor
NPN 1.5A/45V
Philips
BCP 54
QSB858
Q240
SMD transistor
PNP 0.1A/30V F<10dB
Philips
BC 858 B
QS1054
Q241
SMD transistor
NPN 1.5A/45V
Philips
BCP 54
QSB848
Q400
SMD transistor
NPN 0.1A/30V F=2dB
Philips
BC 848 B
QF7002
Q401
SMD n-channel FET
60V 0.115A Rds7.5
Siliconix
2N7002-T1
QSB848
Q402
SMD transistor
NPN 0.1A/30V F=2dB
Philips
BC 848 B
QSB848
Q450
SMD transistor
NPN 0.1A/30V F=2dB
Philips
BC 848 B
QSB848
Q510
SMD transistor
NPN 0.1A/30V F=2dB
Philips
BC 848 B
QSB858
Q511
SMD transistor
PNP 0.1A/30V F<10dB
Philips
BC 858 B
QSB848
Q512
SMD transistor
NPN 0.1A/30V F=2dB
Philips
BC 848 B
QF0124
Q513
N-channel fet
55V/17A Rds=0.07
I&R
IRFZ24N
QF0124
Q514
N-channel fet
55V/17A Rds=0.07
I&R
IRFZ24N
RD0101
R100
SMD resistor
100 R 5% 0.125 W
Kamaya
RD0101
R101
SMD resistor
100 R 5% 0.125 W
Kamaya
RD0224
R200
SMD resistor
220 k 5% 0.125 W
Kamaya
RD0103
R201
SMD resistor
10 k 5% 0.125 W
Kamaya
RD0104
R202
SMD resistor
100 k 5% 0.125 W
Kamaya
RD0103
R203
SMD resistor
10 k 5% 0.125 W
Kamaya
RD0152
R204
SMD resistor
1.5 k 5% 0.125 W
Kamaya
RD1241
R205
SMD resistor
240R 1% 0.125 W
Kamaya
RGC 1/10
RD0103
R210
SMD resistor
10 k 5% 0.125 W
Kamaya
RD0101
R220
SMD resistor
100 R 5% 0.125 W
Kamaya
RD0101
R221
SMD resistor
100 R 5% 0.125 W
Kamaya
CODE
PART
DESCRIPT.
VALUE
MANUF.
TYPE
