Product: UDH-50 (Carbox) / OO0700
CE0476 C415 Al elko 47 uF/25 V 7x7mm Philips 2222 097 56479
CD0104 C416 SMD capasitor 100 nF 10% 50 V X7R Philips
CU1106 C417 SMD tantal 10uF/16V AVX TAJB106M016R
CU0225 C418 SMD tantal 2.2uF/16V 20% 4.7x2.6mm Matsushita ECST1CB 225R
CH0105 C419 SMD capasitor 1uF/-20/+80%/16V TaiyoYuden EMK212 F105Z00T
CH0105 C420 SMD capasitor 1uF/-20/+80%/16V TaiyoYuden EMK212 F105Z00T
CH0105 C421 SMD capasitor 1uF/-20/+80%/16V TaiyoYuden EMK212 F105Z00T
CH0105 C430 SMD capasitor 1uF/-20/+80%/16V TaiyoYuden EMK212 F105Z00T
CH0105 C431 SMD capasitor 1uF/-20/+80%/16V TaiyoYuden EMK212 F105Z00T
CD0101 C440 SMD capasitor 100 pF 5% 50 V NP0 Philips
CD0104 C441 SMD capasitor 100 nF 10% 50 V X7R Philips
CH0105 C460 SMD capasitor 1uF/-20/+80%/16V TaiyoYuden EMK212 F105Z00T
CH0105 C461 SMD capasitor 1uF/-20/+80%/16V TaiyoYuden EMK212 F105Z00T
CU0225 C462 SMD tantal 2.2uF/16V 20% 4.7x2.6mm Matsushita ECST1CB 225R
CU1106 C463 SMD tantal 10uF/16V AVX TAJB106M016R
CD0104 C464 SMD capasitor 100 nF 10% 50 V X7R Philips
CE0337 C465 Al elko 330uF/16V 20% 15x8mm Philips 222213555331
CE0476 C466 Al elko 47 uF/25 V 7x7mm Philips 2222 097 56479
CE0337 C467 Al elko 330uF/16V 20% 15x8mm Philips 222213555331
CD0104 C468 SMD capasitor 100 nF 10% 50 V X7R Philips
CD0103 C469 SMD capasitor 10 nF 10% 50 V X7R Philips
CU0105 C480 SMD tantal 1uF/16V 20% 3.2x1.6mm Matsushita ECST1CY 105R
DT0033 D100 SMD Transil 33V71500W SGS-
Thomso
SM15T33A
DZ0180 D200 SMD zener 18V 5% 300mW Philips BZX84C18
DT0033 D230 SMD Transil 33V71500W SGS-
Thomso
SM15T33A
DT0033 D240 SMD Transil 33V71500W SGS-
Thomso
SM15T33A
IR1317 I200 Adjustable regulator 1.2-37V 1.5A National S LM317AT
IR2951 I210 Regulator 100mA 5V adj. 5% National LP2951CM
II8574 I220 8 bit I/O I2C Philips PCF8574T
IA7550 I300 Single op.amp. Toshiba TA 75S01F-TE85L
IC0453 I320 SMD 2x multip./demultip. Toshiba TC4W53F-TE 12L
IA7550 I321 Single op.amp. Toshiba TA 75S01F-TE85L
IC0453 I322 SMD 2x multip./demultip. Toshiba TC4W53F-TE 12L
IA7550 I330 Single op.amp. Toshiba TA 75S01F-TE85L
IA1905 I410 Audio power amplifier 5W/20V/4ohm SGS/
Thomso
TDA1905
IC0453 I430 SMD 2x multip./demultip. Toshiba TC4W53F-TE 12L
IC0453 I431 SMD 2x multip./demultip. Toshiba TC4W53F-TE 12L
IA7550 I440 Single op.amp. Toshiba TA 75S01F-TE85L
IA1905 I460 Audio power amplifier 5W/20V/4ohm SGS/
Thomso
TDA1905
LA3117 L100 Inductor 110uH 3A R=0.07ohm Fuji SL03B111BE
QF9024 Q200 SMD p-channel FET 60V 9A Rds=0.28 I&R IRFR9024TR
QF7002 Q201 SMD n-channel FET 60V 0.115A Rds7.5 Siliconix 2N7002-T1
QSB858 Q230 SMD transistor PNP 0.1A/30V F<10dB Philips BC 858 B
QS1054 Q231 SMD transistor NPN 1.5A/45V Philips BCP 54
QSB858 Q240 SMD transistor PNP 0.1A/30V F<10dB Philips BC 858 B
QS1054 Q241 SMD transistor NPN 1.5A/45V Philips BCP 54
QSB848 Q400 SMD transistor NPN 0.1A/30V F=2dB Philips BC 848 B
QF7002 Q401 SMD n-channel FET 60V 0.115A Rds7.5 Siliconix 2N7002-T1
QSB848 Q402 SMD transistor NPN 0.1A/30V F=2dB Philips BC 848 B
QSB848 Q450 SMD transistor NPN 0.1A/30V F=2dB Philips BC 848 B
RD0224 R200 SMD resistor 220 k 5% 0.125 W Kamaya
RD0103 R201 SMD resistor 10 k 5% 0.125 W Kamaya
RD0104 R202 SMD resistor 100 k 5% 0.125 W Kamaya
RD0103 R203 SMD resistor 10 k 5% 0.125 W Kamaya
RD0152 R204 SMD resistor 1.5 k 5% 0.125 W Kamaya
RD1241 R205 SMD resistor 240R 1% 0.125 W Kamaya RGC 1/10
CODE PART DESCRIPT. VALUE MANUF. TYPE
