27.1.1999
4A0701GB.__1 15
Product: TDP-52-SN3 (Sigma Gold) / OA0701 Proc./
CH0105 C440 SMD capasitor 1uF/-20/+80%/16V TaiyoYuden EMK212 F105Z00T
CD0104 C443 SMD capasitor 100 nF 10% 50 V X7R Philips
CD0104 C444 SMD capasitor 100 nF 10% 50 V X7R Philips
CH0105 C446 SMD capasitor 1uF/-20/+80%/16V TaiyoYuden EMK212 F105Z00T
CF0331 C447 SMD capasitor 330 pF 5% 50 V NP0 Philips
CF0223 C451 SMD capasitor 22 nF 10% 50 V X7R Philips
CD0223 C452 SMD capasitor 22 nF 10% 50 V X7R Philips
CF0220 C458 SMD capasitor 22 pF 5% 50 V NP0 Philips
CF0220 C459 SMD capasitor 22 pF 5% 50 V NP0 Philips
CF0221 C502 SMD capasitor 220 pF 5% 50 V NP0 Philips
CF0223 C510 SMD capasitor 22 nF 10% 50 V X7R Philips
DS1070 D201 SMD diode pair 70V/100mA common cathode Philips BAV 70W
DS1070 D202 SMD diode pair 70V/100mA common cathode Philips BAV 70W
DS1070 D203 SMD diode pair 70V/100mA common cathode Philips BAV 70W
DY0054 D205 Shottky diode Philips BAT 54
DS1070 D206 SMD diode pair 70V/100mA common cathode Philips BAV 70W
DS1056 D301 SMD diode pair 70V/100mA common anode Philips BAW 56W
DS1099 D401 SMD diode pair 70 V 200 mA Philips BAV 99W 115
OO0020 I101 Answer module Elcoteq
IR7250 I201 Regulator 5V /100mA TexasInstr TPS7250QDR
IR8850 I202 SMD regulator 5V/30mA SeikoInstr S-8850AF-TF
IM0256 I301 SRAM CMOS 32kx8 5V Samsung KM62256CLTG-10L
IM2010 I302 Flash memory 2Mb Intel E28F020-150
IA7550 I303 Single op.amp. Toshiba TA 75S01F-TE85L
IP6810 I304 Prosessor (Peippo) 512 EEPROM, 8A/D, no ROM Motorola MC68HC11A1FU
IG8001 I305 ASIC SeikoEpson SLA919SF1V
IX2339 I405 Audio processor CMOS base band pros AsahiKasei AK2339
IP6832 I503 Processor (SIS) 8k maskPROM,512EEPROM Motorola MC68HC11A8 FU
LF0003 L150 EMI filter 50MHz=65ohm +-40% Murata BLM11B141DPTM00-
LF0003 L151 EMI filter 50MHz=65ohm +-40% Murata BLM11B141DPTM00-
LF0003 L160 EMI filter 50MHz=65ohm +-40% Murata BLM11B141DPTM00-
QS0858 Q101 SMD transistor PNP 0.1A/30V hFE 125-800 Philips BC858BW
QS0848 Q102 SMD transistor NPN 0.1A/30V hFE 110-800 Philips BC848BW, 115
QS0858 Q105 SMD transistor PNP 0.1A/30V hFE 125-800 Philips BC858BW
QS0848 Q106 SMD transistor NPN 0.1A/30V hFE 110-800 Philips BC848BW, 115
QF7002 Q202 SMD n-channel FET 60V 0.115A Rds7.5 Siliconix 2N7002-T1
QS0848 Q203 SMD transistor NPN 0.1A/30V hFE 110-800 Philips BC848BW, 115
QS0848 Q210 SMD transistor NPN 0.1A/30V hFE 110-800 Philips BC848BW, 115
QS0848 Q301 SMD transistor NPN 0.1A/30V hFE 110-800 Philips BC848BW, 115
QS0848 Q302 SMD transistor NPN 0.1A/30V hFE 110-800 Philips BC848BW, 115
QS0848 Q305 SMD transistor NPN 0.1A/30V hFE 110-800 Philips BC848BW, 115
QF7002 Q401 SMD n-channel FET 60V 0.115A Rds7.5 Siliconix 2N7002-T1
RF0103 R101 SMD resistor 10 k 5% 0.125 W Kamaya
RF0103 R102 SMD resistor 10 k 5% 0.125 W Kamaya
RF0472 R103 SMD resistor 4.7 k 5% 0.125 W Kamaya
RF0472 R104 SMD resistor 4.7 k 5% 0.125 W Kamaya
RF0103 R105 SMD resistor 10 k 5% 0.125 W Kamaya
RF0104 R106 SMD resistor 100 k 5% 0.125 W Kamaya
RF0104 R107 SMD resistor 100 k 5% 0.125 W Kamaya
RF0104 R108 SMD resistor 100 k 5% 0.125 W Kamaya
RF0101 R109 SMD resistor 100 R 5% 0.125 W Kamaya
RF0103 R110 SMD resistor 10 k 5% 0.125 W Kamaya
RF0105 R111 SMD resistor 1 M 5% 0.125 W Kamaya
RF0102 R121 SMD resistor 1 k 5% 0.125 W Kamaya
RF0102 R122 SMD resistor 1 k 5% 0.125 W Kamaya
RF0102 R123 SMD resistor 1 k 5% 0.125 W Kamaya
RF0102 R124 SMD resistor 1 k 5% 0.125 W Kamaya
RF0102 R125 SMD resistor 1 k 5% 0.125 W Kamaya
RF0102 R126 SMD resistor 1 k 5% 0.125 W Kamaya
RF0102 R127 SMD resistor 1 k 5% 0.125 W Kamaya
CODE PART DESCRIPT. VALUE MANUF. TYPE
