SIGMA BENEFON TDP-52-SN3 User Manual
Page 82
27.1.1999
4Y0725GB
48
Product: TDP-52-SN3 (Sigma Gold) / OY0725-RF
RF0822
R410
SMD resistor
8.2 k 5% 0.125 W
Kamaya
RF0222
R411
SMD resistor
2.2 k 5% 0.125 W
Kamaya
RF0151
R412
SMD resistor
150 R 5% 0.125 W
Kamaya
RF0220
R420
SMD resistor
22 R 5% 0.125 W
Kamaya
RF0472
R421
SMD resistor
4.7 k 5% 0.125 W
Kamaya
RF0152
R422
SMD resistor
1.5 k 5% 0.125 W
Kamaya
RF0151
R425
SMD resistor
150 R 5% 0.125 W
Kamaya
RF0151
R426
SMD resistor
150 R 5% 0.125 W
Kamaya
RF0150
R429
SMD resistor
15 R 5% 0.125 W
Kamaya
RF0680
R430
SMD resistor
68 R 5% 0.125 W
Kamaya
RF0151
R431
SMD resistor
150 R 5% 0.125 W
Kamaya
RF0150
R432
SMD resistor
15 R 5% 0.125 W
Kamaya
RF0331
R433
SMD resistor
330 R 5% 0.125 W
Kamaya
RF0222
R440
SMD resistor
2.2 k 5% 0.125 W
Kamaya
RF0472
R441
SMD resistor
4.7 k 5% 0.125 W
Kamaya
RF0472
R442
SMD resistor
4.7 k 5% 0.125 W
Kamaya
RF0100
R443
SMD resistor
10 R 5% 0.125 W
Kamaya
RF0221
R450
SMD resistor
220 R 5% 0.125 W
Kamaya
RF0470
R451
SMD resistor
47 R 5% 0.125 W
Kamaya
RF0101
R460
SMD resistor
100 R 5% 0.125 W
Kamaya
RF0823
R461
SMD resistor
82 k 5% 0.125 W
Kamaya
RF0183
R463
SMD resistor
18 k 5% 0.125 W
Kamaya
RF0103
R464
SMD resistor
10 k 5% 0.125 W
Kamaya
RF0472
R465
SMD resistor
4.7 k 5% 0.125 W
Kamaya
RF0473
R483
SMD resistor
47 k 5% 0.125 W
Kamaya
RF0473
R600
SMD resistor
47 k 5% 0.125 W
Kamaya
RF0334
R610
SMD resistor
330 k 5% 0.125 W
Kamaya
RF0102
R611
SMD resistor
1 k 5% 0.125 W
Kamaya
RF0471
R612
SMD resistor
470 R 5% 0.125 W
Kamaya
RF0152
R613
SMD resistor
1.5 k 5% 0.125 W
Kamaya
RF0220
R620
SMD resistor
22 R 5% 0.125 W
Kamaya
RF0101
R621
SMD resistor
100 R 5% 0.125 W
Kamaya
RF0392
R622
SMD resistor
3.9 k 5% 0.125 W
Kamaya
RF0102
R623
SMD resistor
1 k 5% 0.125 W
Kamaya
RF0470
R624
SMD resistor
47 R 5% 0.125 W
Kamaya
RF0391
R630
SMD resistor
390 R 5% 0.125 W
Kamaya
RF0100
R631
SMD resistor
10 R 5% 0.125 W
Kamaya
RF0391
R632
SMD resistor
390 R 5% 0.125 W
Kamaya
RF0184
R640
SMD resistor
180 k 5% 0.125 W
Kamaya
RF0103
R641
SMD resistor
10 k 5% 0.125 W
Kamaya
RF0103
R642
SMD resistor
10 k 5% 0.125 W
Kamaya
RF0104
R643
SMD resistor
100 k 5% 0.125 W
Kamaya
VN0220
V600
SMD connector female
20pin
Suyin
12750A-20
OD0720
X100
Duplexer Nord.
Rx 465Mhz, Tx 455MHz
Solitra
NBS 4502
XM0006
X102
Dual balanced mixcer
450 MHz
MiniCircui
RMS-1LL
XW7725
X103
SAW IF-filter
77.25MHZ, I/O 1.6K//2.3pF
Murata
SAFC77.250MA53X
XC3450
X201
Ceramic IF-filter
450Khz
Murata
CFUCG450E
XC4450
X202
Ceramic IF-filter
450kHz
Murata
CFUCG450F
XR1650
X301
Ceramic coaxial resonato
650MHz 4x4x13mm Q>250
Siemens
B69614-G0655-B42
XO3128
X360
SMD VCTCXO
12.8 MHZ
TEW
TXS 1144M
XR1550
X401
Ceramic coaxial resonato
550MHz 4x4x14,5mm Q>250
Siemens
B69614-G0550-BA4
XI0005
X600
Directional coupler
NMT450
MKT Taisei
DCS3120-09
LF0061
X610
SMD EMI suppression filt
4700pF/2A 1.6x6.8mm
Murata
NFM61R30T472
MD0306
Y1
Tx-fastening plate
Telemetall
931584 41
MD0800
Y133
Tx-VCO cover
10 x 23,3mm
SMC Ltd Oy
95194240
MD0801
Y135
Rx-VCO cover
21,3 x 9,8mm
SMC Ltd Oy
95194140
MD0305
Y2
Shield plate for Tx
Telemetall
931583 41
QA4931
Y302
SMD RF-tarnsistor
NPN 9GHz/NF1.2dB/G13dB
Sanyo
2SC4931-B2
QA4931
Y321
SMD RF-tarnsistor
NPN 9GHz/NF1.2dB/G13dB
Sanyo
2SC4931-B2
QA4931
Y411
SMD RF-tarnsistor
NPN 9GHz/NF1.2dB/G13dB
Sanyo
2SC4931-B2
CODE
PART
DESCRIPT.
VALUE
MANUF.
TYPE
