Introduction
Printer Components
Use Figures 1.1 through 1.3 to identify the main components of your
printer.
Front View
Inside Front View
Face down
output stacker
Paper support
Cassette (250 sheet)
Option Cassette
(250 sheet)
Multi-Purpose Tray
(MP Tray)
Control panel
Control board cover
(provides access to SIMM
slots for adding/removing
additional memory)
Top cover
Toner cartridge
Top cover release
button
Paper level indicator
Figure 1.1
Figure 1.2
