– 5 –
REMOTE COMMAND
Stop sending 30[H] ( ‘0’ )
PLAY 31[H] ( ‘1’ )
PA USE 32[H] ( ‘2’ )
STOP 33[H] ( ‘3’ )
F. F. 34[H] ( ‘4’ )
REW. 35[H] ( ‘5’ )
REC 36[H] ( ‘6’ )
NEXT 37[H] ( ‘7’ )
PREV. 38[H] ( ‘8’ )
POWER ON 39[H] ( ‘9’ )
POWER STANDBY 3A[H] ( ‘:’ )
• Remote command
Specify the command that you want to send.
Because the SRP-X700P keeps sending the CONTROL S signal since its starts sending the “REMOTE COMMAND” of 31[H] - 3A[H]
until it the “Stop sending command” 30[H] is sent, the computer must surely send the “Stop sending command” 30[H] after it sends the
command of 31[H] - 3A[H] once.
Example: When activating PLAY (playback) of LINE3
43[H] 52[H] 43[H] 53[H] 31[H] 31[H] 0D[H] (‘C R C S 1 1 CR’)
LEVEL DOWN: 43[H] 4C[H] 56[H] 2D[H] (‘CLV–’)
This command is used to decrease the sound volume of the specified channel.
When this command is sent, the sound volume keeps decreasing. When the LEVEL UP/DOWN STOP command that is described later, is
sent, the sound volume stops decreasing.
Variable range of a sound volume is from –
∞ to +10 dB when the sound volume is set to the reference level 0 dB.
• Packet format
43[H] 4C[H] 56[H] 2D[H] “parameter” 0D[H]
• Parameter
Specify the channel that you want to use, as the parameter.
Example: When decreasing the sound volume of LINE4
43[H] 4C[H] 56[H] 2D[H] 37[H] 0D[H] (‘C L V - 7 CR’)
CHANNEL CHANNEL
MIC1/WL1 INPUT 30[H] ( ‘0 ’ ) LINE OUTPUT5 3C[H] ( ‘< ’ )
MIC2/WL2 INPUT 31[H] ( ‘1 ’ ) LINE OUTPUT6 3D[H] ( ‘= ’ )
MIC3 INPUT 32[H] ( ‘2 ’ ) LINE OUTPUT7 3E[H] ( ‘> ’ )
MIC4 INPUT 33[H] ( ‘3 ’ ) LINE OUTPUT8 3F[H] ( ‘? ’ )
MIC5/LINE1 INPUT 34[H] ( ‘4 ’ ) MASTER A 40[H] ( ‘@ ’ )
MIC6/LINE2 INPUT 35[H] ( ‘5 ’ ) MASTER B 41[H] ( ‘A ’ )
LINE 3 INPUT 36[H] ( ‘6 ’ ) REMOTE 1 42[H] ( ‘B ’ )
LINE 4 INPUT 37[H] ( ‘7 ’ ) REMOTE 2 43[H] ( ‘C ’ )
LINE OUTPUT1 38[H] ( ‘8 ’ ) REMOTE 3 44[H] ( ‘D ’ )
LINE OUTPUT2 39[H] ( ‘9 ’ ) REMOTE 4 45[H] ( ‘E ’ )
LINE OUTPUT3 3A[H] ( ‘: ’ ) REMOTE 5 46[H] ( ‘F ’ )
LINE OUTPUT4 3B[H] ( ‘; ’ ) REMOTE 6 47[H] ( ‘G ’ )
