– 42 –
REC OUT PARAMETER REQUEST : 52[H] 4F[H] 4D[H] 33[H],32[H] (‘ROR1,2’)
This command is used to read parameter of the desired single channel of the REC OUT 1 and 2 from the SRP-X700P.
The commands that correspond to the respective channels are shown below.
• Packet format
52[H] 4F[H] 52[H] 31[H] “parameter” 0D[H]
(In the case of REC OUT 1)
• Parameter
Specify the scene No. of the scene memory that you want to read, as the parameter.
Method of specifying the scene No. is the same as that of the GROUP FADER command. See page 20.
• Return packet format
When communication with the SRP-X700P is established with success, the parameter is returned together with ACK (41[H] (‘A’)) in the
order shown below.
41[H] “parameter” 0D[H]
The parameter is the same as the 9 bytes of the REC OUT1, 2 commands’ parameter from which the scene No. is exempted.
REMOTE : 43[H] 53[H] 49[H] 4F[H] (‘CSIO’)
This command is used to set the CONTROL S OUTPUT and the PROJECTOR CONTROL.
• Packet format
43[H] 53[H] 49[H] 4F[H] “parameter” 0D[H]
• Parameter
The parameter consists of the 24 bytes all the time in the order as shown in the table below.
The 24th byte should always be set to the fixed value (30[H] (‘0’)).
CHANNEL Command
REC OUT 1 52[H] 4F[H] 52[H] 31[H] ‘ROR1’
REC OUT 2 52[H] 4F[H] 52[H] 32[H] ‘ROR2’
byte byte
1st LINE3 MACHINE TYPE 13th LINE4F MACHINE TYPE
2nd LINE3 CONNECTED CHANNEL 14th LINE4F CONNECTED CHANNEL
3rd LINE4A MACHINE TYPE 15th CONTROL S I/F TYPE
4th LINE4A CONNECTED CHANNEL 16th PJ CONTROL
5th LINE4B MACHINE TYPE 17th LINE4 A SIGNAL DEFINE
6th LINE4B CONNECTED CHANNEL 18th LINE4 B SIGNAL DEFINE
7th LINE4C MACHINE TYPE 19th LINE4 C SIGNAL DEFINE
8th LINE4C CONNECTED CHANNEL 20th LINE4 D SIGNAL DEFINE
9th LINE4D MACHINE TYPE 21st LINE4 E SIGNAL DEFINE
10th LINE4D CONNECTED CHANNEL 22nd LINE4 F SIGNAL DEFINE
11th LINE4E MACHINE TYPE 23rd PROJECTOR PROTOCOL
12th LINE4E CONNECTED CHANNEL 24th 30[H] (‘0‘) fixed
