– 12 –
MIC INPUT –
∞
Turning on/off of the -
∞ indicators of MIC1/WL1 to MIC6/LINE2 is indicated by the 8-bit data.
bit7 bit6 bit5 bit4 bit3 bit2 bit1 bit0
0 1 MIC6/ MIC5/ MIC4 MIC3 MIC2/ MIC1/
LINE2 LINE1 WL2 WL1
When the corresponding bit is ‘1’, – ∞ indicator turns on. When the corresponding bit is ‘0’, –∞ indicator turns off.
Bit-6 and bit-7 are fixed all the time.
LINE INPUT OVER GAIN
Turning on/off of the – ∞ indicator of LINE3 and 4 is indicated by the 8-bit data.
bit7 bit6 bit5 bit4 bit3 bit2 bit1 bit0
0 1 0 0 0 0 LINE4 LINE3
When the corresponding bit is ‘1’, – ∞ indicator turns on. When the corresponding bit is ‘0’, -∞ indicator turns off.
Bit-2 to bit-7 are fixed all the time.
LINE OUTPUT1-6 OVER GAIN
Turning on/off of the OVER GAIN indicators of LINE OUTPUT1 to 6 is indicated by the 8-bit data.
bit7 bit6 bit5 bit4 bit3 bit2 bit1 bit0
0 1 OUT6 OUT5 OUT4 OUT3 OUT2 OUT1
When the corresponding bit is ‘1’, the OVER GAIN turns on. When the corresponding bit is ‘0’, the OVER GAIN turns off.
Bit-6 and bit-7 are fixed all the time.
LINE OUTPUT7,8 OVER GAIN
Turning on/off of the OVER GAIN indicators of LINE OUTPUT7 and 8 is indicated by the 8-bit data.
bit7 bit6 bit5 bit4 bit3 bit2 bit1 bit0
0 1 0 0 0 0 OUT8 OUT7
When the corresponding bit is ‘1’, the OVER GAIN turns on. When the corresponding bit is ‘0’, the OVER GAIN turns off.
Bit-2 to bit-7 are fixed all the time.
LINE OUTPUT1-6 –
∞
Turning on/off of the –
∞ indicators of LINE OUTPUT1 to 6 is indicated by the 8-bit data.
bit7 bit6 bit5 bit4 bit3 bit2 bit1 bit0
0 1 OUT6 OUT5 OUT4 OUT3 OUT2 OUT1
When the corresponding bit is ‘1’, -
∞ indicator turns on. When the corresponding bit is ‘0’, –∞ indicator turns off.
Bit-6 and bit-7 are fixed all the time.
LINE OUTPUT7,8 –
∞
Turning on/off of the –
∞ indicator of OUTPUT7 and 8 is indicated by the 8-bit data.
bit7 bit6 bit5 bit4 bit3 bit2 bit1 bit0
0 1 0 0 0 0 OUT8 OUT7
When the corresponding bit is ‘1’, – ∞ indicator turns on. When the corresponding bit is ‘0’, –∞ indicator turns off.
Bit-2 to bit-7 are fixed all the time.
