– 41 –
PARALLEL I/O PARAMETER REQUEST : 52[H] 50[H] 49[H] 4F[H] ('RPIO')
This command is used to read setup of the REMOTE PARALLEL terminal from the SRP-X700P.
• Packet format
52[H] 50[H] 49[H] 4F[H] 0D[H]
• Return packet format
When communication with the SRP-X700P is established with success, the parameter is returned together with ACK (41[H] (‘A’)) in the
order shown below.
41[H] “parameter” 0D[H]
The parameter is the same as the 44 bytes of the PARALLEL I/O command parameter from which the scene No. is exempted.
REC OUT : 43[H] 4F[H] 52[H] 31[H],32[H] (‘COR1,2’)
This command is used to implement setting up the desired single channel of the REC OUT 1 and 2.
Various setups can be memorized in the scene memories by specifying these scene Nos.
The commands that correspond to the respective channels are shown below.
• Packet format
43[H] 4F[H] 52[H] 31[H] “parameter” 0D[H]
(In the case of REC OUT 1)
• Parameter
The parameter consists of the 10 bytes all the time in the order as shown in the table below.
When you specify NONE (30[H] ‘0’) as the scene No. in the 1st byte, you can establish the present setup.
At the same time, when you specify the scene No. (31[H] (‘1’) through 44[H] (‘D’)), the parameters of the subsequent 2nd to 10th bytes
are written in the scene memory.
Method to set the scene No. and index is the same as that of the GROUP FADER command. See pages 20 and 21.
Method to set the REF LEVEL is the same as that of the LINE OUTPUT3-8 commands. See page 31.
For the packet example, see the example of the LINE 3 INPUT command on page 26. However, the parameter length becomes 10 bytes.
CHANNEL Command
REC OUT 1 52[H] 4F[H] 52[H] 31[H] ‘ROR1’
REC OUT 2 52[H] 4F[H] 52[H] 32[H] ‘ROR2’
byte Parameter name
1st SCENE No.
2nd-9th INDEX
10th REF LEVEL
