MIC MUTING
Status of muting of MIC1/WL1 to MIC6/LINE2 is indicated by the 8-bit data.
bit7 bit6 bit5 bit4 bit3 bit2 bit1 bit0
0 1 MIC6/ MIC5/ MIC4 MIC3 MIC2/ MIC1/
LINE2 LINE1 WL2 WL1
When the corresponding bit is ‘1’, the audio is muted. When the corresponding bit is ‘0’, muting is released.
Bit-6 and bit-7 are fixed all the time.
LINE INPUT MUTING
Status of muting of LINE3 and 4 is indicated by the 8-bit data.
bit7 bit6 bit5 bit4 bit3 bit2 bit1 bit0
0 1 0 0 0 0 LINE4 LINE3
When the corresponding bit is ‘1’, the audio is muted. When the corresponding bit is ‘0’, muting is released.
Bit-2 to bit-7 are fixed all the time.
LINE OUTPUT1-6 MUTING
Status of muting of OUTPUT1 to 6 is indicated by the 8-bit data.
bit7 bit6 bit5 bit4 bit3 bit2 bit1 bit0
0 1 OUT6 OUT5 OUT4 OUT3 OUT2 OUT1
When the corresponding bit is ‘1’, the output signal is muted. When the corresponding bit is ‘0’, muting is released.
Bit-6 and bit-7 are fixed all the time.
LINE OUTPUT7,8/REC OUT1,2/SPEAKER OUTPUT 1,2 MUTING
Status of muting of OUTPUT7 and 8/RECOUT1 and 2/SPEAKER OUT1 and 2 is indicated by the 8-bit data.
bit7 bit6 bit5 bit4 bit3 bit2 bit1 bit0
0 1 SPK2 SPK1 REC2 REC1 OUT8 OUT7
When the corresponding bit is ‘1’, the output signal is muted. When the corresponding bit is ‘0’, muting is released.
Bit-6 and bit-7 are fixed all the time.
MASTER MUTING
Status of muting of MASTER A and B faders among the GROUP FADER is indicated by the 8-bit data.
bit7 bit6 bit5 bit4 bit3 bit2 bit1 bit0
0 1 0 0 0 0 MASTER B MASTER A
When the corresponding bit is ‘1’, the MASTER fader is muted. When the corresponding bit is ‘0’, muting is released.
Bit-2 to bit-7 are fixed all the time.
