5-16
S UPER S ERVER 6015B-3/6015B-T User's Manual
ATX PS/2 Keyboard and
PS/2 Mouse Ports
The ATX PS/2 keyboard and the PS/2
mouse ports are located beside the
USB ports. See the table on the right
for pin defi nitions.
Power LED/Speaker
On the JD1 header, pins 1-3 are for
a power LED, pins 4-7 are for the
speaker. See the table on the right for
speaker pin definitions. Note: The
speaker connector pins are for use
with an external speaker. If you wish
to use the onboard speaker, you
should close pins 6-7 with a jumper.
PS/2 Keyboard and
Mouse Ports
Pin Defi nitions
Pin# Defi nition
1 Data
2 NC
3 Ground
4 VCC
5 Clock
6 NC
Speaker Connector
Pin Defi nitions (JD1)
Pin # Function Defi nition
4 + Speaker data (red wire)
5 Key No connection
6 Key
7 Speaker data
Universal Serial Bus
Headers
Four additional USB headers (at
JUSB2 and JUSB3) are included on
the serverboard. These may be used
for front side access. A USB cable
(not included) is needed for the con-
nection. See the table on the right for
pin defi nitions.
Universal Serial Bus Headers
Pin Defi nitions (JUSB2, JUSB3)
USB2
Pin # Defi nition USB3, USB4
Pin # Defi nition
1 +5V 1 +5V
2 PO- 2 PO-
3 PO+ 3 PO+
4 Ground 4 Ground
5 Key 5 NC
Overheat LED
Connect an LED to the JOH1 header
to provide warning of a chassis over-
heating condition. See the table on the
right for pin defi nitions.
Overheat LED
Pin Defi nitions
(JOH1)
Pin# Defi nition
1 +5V
2 OH Active
