Chapter 5: Advanced Serverboard Setup
5-21
Compact Flash Master/
Slave
The JCF1 jumper allows you to as-
sign either master or slave status to
a compact fl ash card populating the
JIDE#2 slot. See the table on the right
for jumper settings.
Compact Flash
Master/Slave
Jumper Settings (JCF1)
Jumper Setting Defi nition
Closed Master
Open Slave
5-10 Onboard Indicators
JLAN1/JLAN2 LEDs
The Ethernet ports (located beside
the VGA port) have two LEDs. On
each port, one LED indicates activity
while the other LED may be green,
amber or off to indicate the speed of
the connection. See the table on the
right for the functions associated with
the connection speed LED.
JLAN LED
(Connection Speed Indicator)
LED Color Defi nition
Off 10 MHz
Green 100 MHz
Amber 1 GHz
SAS Controller Enable
(6015B-3 only)
JPS1 enables or disables the Adapt-
ec 9140W SAS controller on the
serverboard. See the table on the
right for jumper settings. The default
setting is enabled.
SAS Controller Enable
Jumper Settings (JPS1)
Jumper Setting Defi nition
Pins 1-2 Enabled
Pins 2-3 Disabled
SMB to PCI Slots
Jumpers JI 2 C1 and JI 2 C2 allow you to
connect the PCI-X/PCI-E slots to the
System Management Bus . The default
setting is disabled. See the table on the
right for jumper settings.
SMBus to PCI
Jumper Settings (JI 2 C1, JI 2 C2)
Jumper Setting Defi nition
Pins 1-2 Enabled
Open Disabled
