NEW ZIPPIE TS/TS PAGE 45
HIGH WHEEL LOCK PULL (LONG SLIDE)
Pos. Item Number Description Remarks
1 483027 1/4 x 1/4 ALUM SPACER BLK
2 880904 GRADE AID PLATE W/ WHEEL BLK RIGHT
2 880905 GRADE AID PLATE W/ WHEEL BLK LEFT
3 561028 1/4" NYLON WASHER
4 560500-QU HB PLASTIC COVER
4,5 881798 WHEEL LOCK ASSM PULL RIGHT
4,5 881799 WHEEL LOCK ASSM PULL LEFT
6 560126 .250 ID .312 OD BUSHING PLST
7 226110 1/4-28 x 1 BH C/S
7 226130 1/4-28 x 1 1/2 BH C/S (W/GRADE AID)
8 550447 WHL LCK SLIDE BLOCK LNG
9 201100-QU 1/4-28 NYLOCK NUT THIN
10 226112 1/4-28 x 1 SOC C/S BLK
11 262114 1/4 WASHER HI COLLAR LOCK ZN
12 550659 CLAMP 1 1/4" RECESS HALF BLK
13 550658 CCLAMP 1 1/4" THREADED BLK
10-13 880594 WHL LCK/ 1AD CLMP ASSM BLK
3-9 881948 WHL LOCK PULL LARGE W/O CLMP RIGHT
3-9 881949 WHL LOCK PULL LARGE W/O CLMP LEFT
1-9 882025 WHL LOCK PULL LARGE W/GRADE AID RIGHT
1-9 882026 WHL LOCK PULL LARGE W/GRADE AID LEFT
