66 | EXTENDING YOUR USB 2.0 CABLE
This external power supply should meet the following specifications.
Extending the USB Connection Between Your Interactive Whiteboard and Your Computer
Specification Parameter
Power Supply • 5.0 V DC with 5% or better regulation
• 1.5 A of current (typical draw - 500 mA)
Connector 1/4" Ч 1/8" (5.5 Ч 2.1 mm), center positive
coaxial connector
International Support 120-240 VAC Input
Certifications and Compliance Limited Power Source (LPS) requirements
of CSA/UL/IEC/EN 60950-1
A power supply connects
to the receptacle on the
bottom of the USB hub
at the back of your
interactive whiteboard.
16' (5 m) 16' (5 m)
The 16' (5 m) passive
SMART USB 2.0 cable
(included) connects to your
SMART Board V280
interactive whiteboard. A 16' (5 m) SMART Active
USB Extension Cable
(Part No. USB-XT)
connects the USB 2.0
cable and your computer.
