ASSEMBLY
1900 07/10
Assembly Section 3-9
© 2010 Alamo Group Inc.
ASSEMBL
Y
•
Raise the stand legs into the work position and
secure with lock pins.
•
Tighten check chains and/or stabilizer bars.
•
Fit machine controls into the cab. (Optional
Cables available)
•
Measure P.T.O. and cut to dimension shown.
Note: for subsequent use on different tractors
measure again - there must be a minimum shaft
overlap of 150mm.
