OPERATION
1900 07/10 Operation Section 4-3
© 2010 Alamo Group Inc.
OPERA
T
ION
1. Standard Equipment and Specifications
Standard Specifications
Tractor Requirements
Minimum Tractor HP Requirements 65 HP PTO
Minimum Tractor Weight 7716lbs (3500kg)
Machine Specifications
Maximum Machine Reach
18’ (5.5m)
19’-7” (6.0m)
Machine weight with flailhead 2998lbs (1360kg)
3042lbs (1380kg)
Power Arm Horsepower 65hp
Oil Tank Capacity 53g (200ltr)
Hydraulics
Gear Totally Independent Standard
Method of Attachment
3-Point Linkage-Mounted Standard
Controls
Cable Control Standard
Machine Equipment
Safety Breakaway - Hydraulic Standard
Road Light Kit Standard
Power Slew Standard
Cable Rotor Control Standard
Window Guards Standard
Power Arm Attachments
F48 Flail Mower
H48 Flail Mower
D58 Sicklebar Mower
