Fig-6
LIGHT BLOCK SHEET
Make sure the sheet figure and put
on proper position.
-4-
6 Use a Light-Block Sheet (provided with projector) corresponding with lens. (Refer to the Type No.
below.) Set Light-Block Sheet through the lens.
Make sure the shape of Light-Block Sheet and be sure to set them as shown in the Fig. 6.
NOTE:
● Be sure to set a Light-Block Sheet as shown in Fig-6.
● Make sure the mark (TOP and BACK) on Light-Block Sheet and set them properly.
Use light-block sheet Type No. TYPE FD1 (PART No. 610 290 9258)
