Sanyo LNS-S03 - Manual

Type of the Cabinet (1) See Page 2
LCD PROJECTOR LENS
MODEL NO. LNS-S03
LENS REPLACEMENT
AND INSTALLATION PROCEDURES
NOTES ON REPLACEMENT AND INSTALLATION
The procedures and the needed pars for lens installation depend on the type of
cabinet. Before installing or replacing the lens, make sure the type of cabinet and be
sure to refer to the Installations corresponding with your projector.
When installing or replacing the lens, make sure the Lens Model No. matches with
your projector. Refer to the catalog, or contact your sales dealer for the proper Lens
Model No.
TYPE OF THE CABINET AND INSTALLATION PROCEDURES
Refer to the Installation procedure corresponding to your projector and install the lens
correctly. (See the chart below.)
Type of the Cabinet (2) See Page 6
1AA6P1P2987-- (IDAJ)
For use the other models (other than above cabinet), contact your sales dealer.
