ARCNET 5 Port HUB Controller
Datasheet
SMSC TMC2005-JT Page 27 Revision 1.1 (07-24-07)
DATASHEET
OPERATIONAL DESCRIPTION
MAXIMUM GUARANTEED RATINGS*
Stresses above those listed may cause permanent damage to the device. This is a stress rating only and functional
operation of the device at these or any other condition above those indicated in the operational sections of this
specification is not implied.
(Note) When powering this device from laboratory or system power supplies, it is important that the Absolute
Maximum Ratings not be exceeded or device failure can result. Some power supplies exhibit voltage spikes or
“glitches” on their output when the AC power is switch on or off. In addition, voltage transients on the AC power line
may appear on the DC output. If this possibility exists it is suggested that a clamp circuit be used.
Vss = 0V
ITEM SYMBOL RATING UNIT
POWER SUPPLY VOLTAGE VDD -0.3 +7.0 V
INPUT VOLTAGE VIN -0.3 VDD +0.3 V
OUTPUT VOLTAGE VOUT -0.3 VDD +0.3 V
AMBIENT TEMPERATURE Tstg -40 +125 °C
STANDARD OPERATING CONDITION
Vss = 0V
ITEM SYMBOL RATING UNIT
POWER SUPPLY VOLTAGE VDD 4.5 – 5.5 V
AMBIENT TEMPERATURE Ta 0 - +85 °C
DC CHARACTERISTIC - INPUT PIN
SYMBOL ITEM CONDITION MIN MAX UNIT
XTLI, nPLLTST 3.5 V
V IH High Level Input Voltage
Others 2.2 V
V IL Low Level Input Voltage 0.8 V
I IH High Level Input Current VIN=VDD -10 10 uA
I IL Low Level Input Current VIN=VSS -10 10 uA
I IL With pull-up Vin=VSS -200 -10 uA
I OZ Output Leak Current VOUT=VDD or VSS -10 10 uA
I DD Dissipation Current Operating 100 mA
