Scag Power Equipment STC61V-23BV - Manual (Page 43)

39
Section 8
1 461854 Cutter Deck Velocity Plus x
461858 Cutter Deck Velocity Plus x
2 43686 Boss, Spring Anchor x x
3 04019-04 Nut, 3/8-16 Serrated Flange x x
4 481625-01 Wing Nut, 3/8-16 x x
5 481632 Anti-Scalp Wheel x x
6 04003-26 Bolt, Carriage 3/8-16 x 4” x x
7 422478 Bracket, Anti-Scalp Wheel x x
8 04017-27 Bolt, Serrated Flange 3/8-16 x 1” x x
9 04043-06 Flatwasher, 5/8” Hardened x x
10 04021-05 Locknut, 3/8-16 Center Lock x x
11 461844 Discharge Chute x
461845 Discharge Chute x
12 04001-11 Bolt, Hex Head 5/16-18 x 1-1/2”, Rear x x
04001-12 Bolt, Hex Head 5/16-18 x 1-3/4”, Front x x
13 04021-10 Nut, Elastic Stop 5/16-18 x x
14 04020-09 Nut, 5/8-11 UNC x x
15 45944 Shaft, Roller x x
16 04001-41 Bolt, Hex Head 5/8-11 x 9-1/2” x x
17 48038 Roller, Rear x x
18 04001-154 Bolt, Hex Head 5/16-18 x 4-3/4” x x
19 04063-08 Key, 1/4 x 1/4 x 2” x x
20 483246 Spring, Idler L.H. x x
21 04043-04 Flatwasher, 3/8” x x
22 04001-176 Bolt, Hex Head 5/16-18 x 1-3/4” Grade 8 x x
23 04019-03 Nut, Serrated Flange 5/16-18 x x
24 04001-51 Bolt, Hex Head 3/8-16 x 3-3/4” x x
25 48100-15 Bushing, .376 ID Oilite x x
26 04030-03 Lockwasher 5/16” x x
27 04040-15 Flatwasher 5/16” x x
28 04001-136 Bolt, Hex Head 3/8-16 x 1-1/2” Gr. 8 x x
29 04021-09 Nut, Elastic Stop 3/8-16 x x
30 04001-31 Bolt, Hex Head 3/8-16 x 2-1/2” x x
31 483247 Spring, Idler R.H. x x
32 424369 Bracket, Spring Anchor L.H. 48V x
424409 Bracket, Spring Anchor L.H. 52V x
33 04110-03 U-Nut, 3/8-16 x x
34 461663 Spindle Assembly x x
35 43589 Shaft, Spindle x x
36 481024 Seal Upper x x
37 481022 Bearing Assembly x x
38 48114-04 Grease Fitting x x
39 48677 Valve, Grease Relief x x
40 43644 Housing, Spindle x x
41 43312 Spacer, Outside x x
42 43296 Spacer, Inside x x
43 481025 Seal, Lower x x
44 43297 Bushing, Bottom x x
45 481035 Nut, Special 1-1/16 - 18 x x
46 43590 Spacer, Spindle x x
47 482877 Cutter Blade 16.5” x
482878 Cutter Blade 18” x
48 483210 Pulley, Idler 5” Dia. x x
49 48224 Bearing x x
50 461940 Idler Arm Assy. x x
48V”& 52V" CUTTER DECKS
Ref. Part
No. No.
Description 48 52
Ref. Part
No. No.
Description 48 52
51 43689 Idler Pivot x x
52 424322 Belt Cover (48V) x
52A 424323 Belt Cover (52V) x
53 48926 Hub, Tapered 1-1/8” Bore x x
54 461946 Idler Arm x x
55 04001-172 Bolt, Hex Head 1/4-20 x 1” Grade 8 x x
56 483282 Pulley 4.75” x
483284 Pulley 5.35” x
57 424208 Turbo Baffle, Bolt On x x
58 451240 Push Arm Shaft x x
59 461516 Push Arm (Includes 64,60,62) x x
60 04020-16 Nut, 5/8-18 UNF x x
61 04021-13 Nut, Elastic Stop 5/8-11 x x
62 48763 Rod End, 5/8 Male RH Thread x x
63 04001-79 Bolt, Hex Head 5/8-11 x 4-1/2” x x
64 48114-04 Grease Fitting, 90 Degree x x
65 483241 Belt, Cutter Deck Drive (48V) x
483242 Belt, Cutter Deck Drive (52V) x
66 04001-09 Bolt, Hex Head 5/16-18 x 1” x x
67 483378 Spring, Discharge Chute x x
68 424173 Baffle Weldment, 48V x
424174 Baffle Weldment, 52V x
69 04003-23 Bolt, Carriage 3/8-16 x 1” x x
70 04021-22 Nut, Elastic Stop 5/16-18 Grade 8 x x
71 04043-04 Flatwasher 3/8” x x
72 483239 Belt, R.H. Cutter Deck x
483240 Belt, R.H. Cutter Deck x
73 48181 Pulley, Idler 5” Dia. x x
74 483283 Pulley, Double Groove x
483285 Pulley, Double Groove x
75 483167 Bolt, Special x x
76 461929 Lever Assy., Deck Level x x
77 04003-40 Bolt, Carriage 7/16-14 x 1-1/4" x x
78 04040-11 Flatwasher, 7/16-.500 x 1.25 x .083 x x
79 04021-11 Nut, Elastic Stop 7/16-14 x x
80 424367 Dust Shield
81 04030-03 Lockwasher 3/8”
82 424376 Bracket, Spring Anchor R.H. x
424377 Bracket, Spring Anchor R.H. x
83 04001-136 Bolt, Hex Head 3/8-16 x 1-1/2” Gr. 8 x x
84 04001-19 Bolt, Hex Head 3/8-16 x 1” x x
85 04001-19 Bolt, Hex Head 3/8-16 x 1” x x
86 04001-136 Bolt, Hex Head 3/8-16 x 1-1/2” Gr. 8 x x
87 43689 Idler Pivot x x
88 04003-12 Bolt, Carraige 5/16-18 x 3/4” x x
89 04040-04 Flatwasher, 5/16” x x
90 04021-04 Nut, Center Lock 5/16-18 x x
91 483176 Wear Pad x x
