Scag Power Equipment STC61V-23BV - Manual (Page 22)

18
Section 4
Figure 4-5 Adjusting Cutting Height
Figure 4-4 Deck Release Lever
4.14 TOWING (optional hitch accessory)
1. Never allow children or others in or on towed
equipment.
2. Tow only with a machine that has a hitch designed
for towing. Do not attach towed equipment except at
the hitch point.
3. Follow manufacturer's recommendations for weight
limit for towed equipment. 250lbs. maximum towing
weight.
4. Never tow on slopes. The weight of the towed
equipment may cause loss of traction and loss of
control.
HEIGHT ADJUSTMENT
PEDAL
LANYARD
PIN
STC 2006 ACH
C U T T I N G H E I G H T 5
4 1 / 4 3 1 / 2 2 1 / 2 X 1 1 / 4
STC 2006 DRL
DECK RELEASE LEVER
5. Travel slowly and allow extra distance to stop.
6. Zero turning with a trailer attached, could cause
damage to the trailer or mower.
