16

36. Grease an M8 x 22mm Shoulder Bolt (39). Attach

the Butterfly Cable (106) to the Right Butterfly
Arm (7) with the Bolt and an M8 Nylon Locknut
(91).

Make sure the flat edge of the Cable is

against the Butterfly Arm.

38. Wrap the Short Cable (108) over* a 90mm Pulley

(63). Attach the Pulley and two Half Finger
Guards (66) to the Double “U”-bracket (61) with
an M10 x 48mm Bolt (84) and an M10 Nylon
Locknut (90).

Make sure the Finger Guards are

oriented as shown.

40.

Locate the Weight Cable (110). Route the Cable
up through the Right Top Frame (5) and over a
90mm Pulley (63). Attach the Pulley inside the
Top Frame with an M10 x 80mm Bolt (75), two
M10 Washers (99), two M10 x 19mm Spacers
(102), and an M10 Nylon Locknut (90).

39. Attach the end of the Short Cable (108) to a “U”-

bracket (50) with an M8 Washer (98) and an M8
Nylon Locknut (91).

Note: Do not completely

tighten the Locknut; it should be tightened so
that only two threads of the Cable show past
the Locknut, as shown in the inset drawing.

37.

Locate the Short Cable (108). Attach the Cable
to the M8 x 96mm Bolt (83) used in step 6 with
an M8 Washer (98), an M8 x 13mm Spacer (103),
and an M8 Nylon Locknut (91).

36

37

39

40

38

91

91

39

91

7

106

Grease

83

98

91

103

108

63

84

66

61

90

66

108

50

98

108

108

63

5

99

99

75

90

110

102

102

2

Flat

Edge
