W1747 20" Planer
PA
RT
S
Stand/Motor Assembly Parts List
REF PART�# DESCRIPTION REF PART�# DESCRIPTION
106 X1747106 FENDER�WASHER�8MM 251 X1747251 INDICATOR�LIGHT�(RED)
107 XPFS02M FLANGE�SCREW�M6-1�X�12 252 X1747252 SWITCH�PLATE
116 XPW03M FLAT�WASHER�6MM 253 X1747253 SWITCH�BOX
139 XPSS14M SET�SCREW�M8-1.25�X�12 254 X1747254 SWITCH�ELBOW�BRACKET
181 XPN09M HEX�NUT�M12-1.75 255 XPW06M FLAT�WASHER�12MM
234 XPFH06M FLAT�HD�SCR�M6-1�X�20 284 X1747284 MOTOR�BRACKET
235 X1747235 COVER 285 X1747285 COLLAR
236 X1747236 STRAIN�RELIEF 286 XPB15M HEX�BOLT�M8-1.25�X�40
237 X1747237 CABINET�STAND 287 XPN03M HEX�NUT�M8-1.25
238 X1747238 FOOT 288 XPW01M FLAT�WASHER�8MM
239 XPTLW02M EXT�TOOTH�WASHER�5MM 289 X1747289 ADJUSTABLE�BOLT�M12-1.75
240 XPS20M PHLP�HD�SCR�M5-.8�X�15 290 X1747290 5�HP�MOTOR�220V�1-PH
241 X1747241 MAGNETIC�SWITCH�ASSEMBLY 290-1 X1747290-1 CAPACITOR�COVER
241-1 X1747241-1 CONTACTOR 290-2 X1747290-2 MOTOR�FAN�COVER
241-2 X1747241-2 MAG�SWITCH�FRONT�COVER 290-3 X1747290-3 MOTOR�FAN
241-3 X1747241-3 THERMAL�OVERLOAD�RELAY 290-4 X1747290-4 S.�CAPACITOR�600MFD/125VAC
241-4 X1747241-4 MAG�SWITCH�BACK�COVER� 290-5 X1747290-5 R.�CAPACITOR�50MFD/350VAC
242 X1747242 STRAIN�RELIEF 290-6 X1747290-6 CENTRIFUGAL�SWITCH
243 X1747243 STRAIN�RELIEF 290-7 X1747290-7 JUNCTION�BOX
244 X1747244 POWER�CORD�10AWG�X�3C 290-8 X1747290-8 MOTOR�LABEL
245 X1747245 MOTOR�CORD�10AWG�X�3C 291 XPK12M KEY�5�X�5�X�30
246 X1747246 SWITCH�PLATE 292 X1747292 MOTOR�PULLEY
247 XPS09M PHLP�HD�SCR�M5-.8�X�10 293 X1747293 NYLOCK�HEX�BOLT�M8-1.25�X�20
248 X1747248 SWITCH�CORD�18AWG�X4C 294 X1747294 BAR
249 X1747249 START�SWITCH 307 XPSS09M SET�SCREW�M8-1.25�X�20
250 X1747250 STOP�SWITCH
