-22-
W1747 20" Planer
O
PE
R
AT
IO
N
S
PLANER PAL ® Magnetic Planer Knife Setting Jigs. Our patented
knife-setting system lets you set straight-type planer knives in per-
fect alignment every time! You can shift nicked knives on 2 1 ⁄
2
"– 4"
cutterheads to get a perfect cut with an accuracy of ±.002". Two jigs
are needed for 15"– 20" planers. Use the STANDARD JIGS for Steel
Knives W1216 (Pair), or the CARBIDE JIGS for Steel or Carbide Knives
W1217 (Pair). �
The SHOP FOX ® Wood Rack System features interchangeable rack
bars and shelf brackets to create simple or elaborate wood racks. 24"
and 48" rack bars can be joined together to provide 6 feet of verti-
cal storage capacity. Easily adjustable 12" and 18" shelf brackets lock
into the rack bars for a secure system. Weight capacity is 300 lbs.
for 12" brackets and 200 lbs. for 18" brackets when wood rack bars
are supported by the floor and weight is evenly distributed. Assembly
instructions included. D2829 24" Wood Rack Bars, D2830 48" Wood
Rack Bars, D283112" Wood Rack Shelf Brackets, and D2832 18" Wood
Rack Shelf Brackets.
