Woodstock SHOP FOX W1756 - Manual (Page 60)

-58-
W1756/W1757 43" Wide-Belt Sander
PA
RT
S
Electrical & Controls Parts List
REF PART�# DESCRIPTION REF PART�# DESCRIPTION
1 X1756001 ELECTRICAL�CONTROL�BOX 18 XPS51M PHLP�HD�SCR�M4-.7�X�30
2 X1756002 HINGE 19 X1756019 TERMINAL�PLATE
3 X1756003 DOOR 20 XPW06 FLAT�WASHER�1/4
4 X1756004 BASE�PLATE 21 XPLW02� LOCK�WASHER�1/4
5 XPN05 HEX�NUT�1/4-20 22 XPB19 HEX�BOLT�1/4-20�X�1/2
6 XPLW02� LOCK�WASHER�1/4 23 X1756023 PU�CONNECTOR�1/2"
7 X1756007 CONTROL�PANEL 24 X1756024 PU�CONNECTOR�3/4"
8 XPS07M PHLP�HD�SCR�M4-.7�X�8 25 X1756025 CABLE�CONNECTOR�1"
9 X1756009 CURRENT�SENSOR 26 X1756026 DIGITAL�AMP�METER
10 X1756010 TRANSFORMER 27 X1756027 START�DELAY�TIMER�LSD
11 X1756011 MAGNETIC�CONTACTOR�LC1-D386 28 X1756028 START�SWITCH
12 X1756012 OVERLOAD�RELAY�LR3D-356�(30-38A)�220V�32A 29 X1756029 STOP�SWITCH
13 X1756013 FUSE�TE10.3�X�38�&�500V�/�4A�X�2 32 X1756032 POWER�INDICATION�LIGHT
14 X1756014 OVERLOAD�RELAY�LR3D-126�(5.5-8A)�220V�6A 33 X1756033 EMERGENCY�STOP�SWITCH
15 X1756015 MAG�CONTACTOR�LC1-096�(W/LOCK) 34 X1756034 WIRE�COLUMN
16 X1756016 MAGNETIC�CONTACTOR�LC1-D326 35 X1756035 COMPUTER
17 X1756017 POWER�WIRE�TERMINAL 36 X1756036 WIRE�COLUMN
37 X1756037 220V-440V�CONVERSION�KIT
37-1 X1756037-1 RELAY�LR3D-216�(12-18A)�#8112�440V�25HP
37-2 X1756037-2 RELAY�LR3D-086�(2.5-4A)�#8114�440V�1HP
W1756/W1757 440 Conversion Kit
