-51-
W1756/W1757 43" Wide-Belt Sander
SE
RV
IC
E
Wiring Box Components 220V
220V Three-
Phase Power
Supply
Junction Block
Amp Meter
Current Sensor
UP/DOWN Table Motor
Contactors
Sanding Motor
Start Delay
Emergency Brake
Contactor
4 Amp Fuses
Feed Belt
(Conveyor) Motor
Contactor
Sanding Motor
Contactors
Feed Belt
(Conveyor) Motor
Overload Relay
Sanding Motor
Overload Relay
Transformer
