97-6132, 97-6151 • REV. 11/04
OPERA
TOR’S MANU
AL
PRESSURE
W
ASHER
30
97-6132, 97-6151 • REV. 11/04
31
PRESSURE
W
ASHER Specifications
HOSE REEL OPTION
HOSE REEL PARTS LIST
ITEM PART NO. DESCRIPTION QTY
1 2-2002 Coupler, 3/8", Female, Brass 1
2 4-02047736 Hose, 3/8", 2 Wire Pressure
Loop 1
3 4-02755030 Hose Reel, 100' Non-Pivot
E-ZEE w/Pin Lock 1
4 90-1996 Screw, 3/" x 3/4" HH NC, Whiz
Loc 4
5 90-20040 Nut, 3/8" Flange, Whiz Loc, NC4
6 95-072900891 Bracket, E-ZEE Hose Reel Right,
Wrinkle Black 1
5
6
4
2
3
1
