24 F45 Issue 6
The Penny and Giles Pilot + control pod
Fig. 35
Programme port
Fig. 36
Red
indicator
lights
Actuator mode function
This will be included on your
remote control pod if you have one
or more electric options fitted to
your chair. Refer to Fig. 35.
Menu select
To chose an electric option press
the mode button until the red lights
are visible on the wheelchair
diagram next to the joystick. Move
the joystick to the left or right to
indicate which function can be
used.
Legrest left Backrest recline
Seat tilt
Legrest right Both legrests
When the desired function has
been chosen you can activate the
electric actuator system.
If you attempt to operate the electric
functions when driving, the chair will
automatically come to a safe stop.
We recommend you only use the
electric options whilst stationary.
Up/down movement
Once the relevant electric option
has been chosen the required
movement is achieved by moving
the joystick forwards or backwards.
Programme port
This will enable an approved service
agent to reprogramme your chair and
also gain useful information when
tracing any faults (Fig. 36).
