14 F45 Issue 6
Fig. 15
Fig. 16
Footrests
Adjusting the footrest length
To adjust the footrest length
remove the screw assembly on the
footrest stem as shown in Fig. 11,
adjust the length to suit. Replace
the bolt assembly and tighten.
Ensure the bolt is firmly located and
tightened prior to use.
Note: The internal footrest stem
may require cutting down in length
to allow the footplate position to be
raised (Fig. 15).
Footplates
The footplates may be flipped up to
aid entry and exit from the chair.
(Fig. 16). Do not use the footplates
to stand on as the full weight of
your body may cause the chair to
tip forwards and damage the
footrests.
Footplate length adjustment
screw assembly
Internal footrest
stem
Footplate
Footplates in raised position
